Calibration Method for Structured Light Vision Sensor Based on Planar Target

Abstract:

The calibration of structured light vision sensor is the key technique in structured light 3D vision measurement. In this paper, a novel method for structured light vision sensor calibration is presented. In our method, a simple 2D planar target is used, and the corresponding world coordinate system is set for the target at different positions as well as the transformation relationships between world coordinate system camera coordinate system and image coordinate system. The intersecting line equations at different positions are unified under the camera coordinate system after processing. Then we can use least square method to fit the structured light equation. The experimental results show that the proposed method is an efficient method with high precision and simple procedure.

• Periodical: Applied Mechanics and Materials (Volumes 71-78)
• Pages: 4321-4324
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.71-78.4321
• Online since: July 2011
• Authors: Zhen Qian Liu, Shun Wang, Yi Xin Zhang
• Keywords: 2D Planar Target, Calibration Method, Structured Light

References

[1] DEWAR R: Robots and Vision'88 Conf. Proceedings, Detroit, 1988, pp.5-13.

[2] Duan Fajie, Liu Fengmei, Yie Shenghua: Chinese Journal of Scientific Instrument, Vol. 21(2000), pp.108-110. in Chinese.

[3] Zhou Fuqiang, Zhang Guangjun: Chinese Journal of mechanical engineering, Vol. 41(2005), No. 3, (2005), pp.175-176.

[4] Xu Li, Zhang Zhi-jiang: Journal of Optoelectronics. Laser, Vol. 20(2009) , pp.1063-1069. in Chinese.

[5] Sun Changku, He Mingxia, Wang Peng: Laser Measurement Technology, (Tianjing University press，2008, ), pp.144-151.

[6] ZHANG Z Y: Seventh International Conference on Computer Vision (ICCV99), (Corfu, Greece, 1999), pp.666-673.

[7] Juyang Weng, Paul Cohen, Marc Herniou: IEEE Transactions on pattern analysis and machine intelligence, VOL. 14(1992), pp.965-980.

DOI: 10.1109/34.159901

[8] TSAI R Y: IEEE Journal of Robotics and Automation, ( 1987), pp.323-344.

[9] STEGER C: IEEE Transactions on Pattern Analysis and machine Intelligence，VOL. 20(1998) p.113～125.
