The Optimization of Directly Buried Heating Pipe Elbow Based on the ANSYS

Abstract:

The two problems restrict the development of directly buried pipeline installation without compensation technology in the heating engineering.Therefore, the intensity of elbow itself is analyzed to optimize the elbow .A new model of elbow is provided .This paper uses ANSYS finite element analysis software to establish a new type of elbow model.We compare and analyze the stress of ordinary elbow which add block and do not add block ; two different types which both have the same wall thickness and new type elbow which have 5 different wall thickness for each elbow.The results show that:(1) the new type elbow can reduce the stress greatly;(2) with the increasing diameter of elbow, the stress of inner elbow decreases gradually. Therefore, this new type of elbow can truly realize non-compensating installation in heating system.

• Periodical: Applied Mechanics and Materials (Volumes 713-715)
• Pages: 187-190
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.713-715.187
• Online since: January 2015
• Authors: Yao Xiang Wang*, Fei Wang, Guo Wei Wang, Yong Gang Lei
• Keywords: Directly Buried Pipeline Installation, Finite Element Simulation, New Type of Elbow, Non-Compensating, Stress

References

[1] Cuixiao Bing. Approximate analysis of the heating load of the buried long-distance pipeline elbow [J]. Journal of East of China University of Petroleum, 1978(02): 54-68.

[2] Dihong Fa, Shizhao Yu. The stress and design method of directly buried pipe elbow [J]. District Heating. 1995(06): 25-30.

[3] Guo Rui ping , Li Guangxin, Chen Lun. Mechanical numerical simulation of"L"-type buried heating pipe [J]. Computational Structural Mechanics And Applications 1996, 13(03): 327-332.

[4] ZHANG Xiao- chen, CHEN Hong- qi, SUN Yun- pu. Stress analyses for direct buried heating pipe elbows [J]. Journal Of Harbin Institute Of Technology, 2003, 35(11): 1369-1371.

[5] Wang Guowei. Large-diameter directly buried heating pipe 90 elbow fatigue life of the finite element analysis. [D]Press, 2010: 71-82(in Chinese).

[6] Fei Wang，Zhangjian Wei. The design of directly buried heating pipeline [M]. China Building Industry Press, (2007).

[7] (Danmark) Lande Lao Fupi(edit) He Ping, Wang Gang(translation). District heating Manual [M]. Harbin Engineering University Press, 1998: 29-31(in Chinese).

[8] ZHAO Lin, FENG Qi-min. Research on methods for establishing FEM model of buried pipelines [J]. 2001(06): 53-57.

[9] (CJJ-T81-2013 Technical specification for directly buried heating pipeline engineering in city[S]. Beijing: China Building Industry Press, (in Chinese).
