Investigation of Sinkage and Trim by Ships in Shallow Water Based on Overset Grid

Abstract:

A study on the navigation behavior for ships in shallow water had been carried out on CFD. The problem of surface ship hulls free of sinkage and trim in shallow water is analyzed numerically by simultaneously solving equations of the Reynolds averaged Navier-Stokes (RANS). The computations, based on the single-phase level set and overset grid, are discretized by finite volume method (FVM). An earth-based reference system is used for the solution to the fluid flow, while a ship-based reference is used to compute the rigid-body equations of motion. A S60 C_B=0.6 ship model is taken as an example to the numerical simulation. Numerical results of the sinkage and trim of the seven Froude Numbers (F_n=0.5~0.8) are compared against experimental data, which have a good agreement.

• Periodical: Applied Mechanics and Materials (Volumes 713-715)
• Pages: 2126-2132
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.713-715.2126
• Online since: January 2015
• Authors: Da Ming Sun*, Ji Yong Liu, Qing Wen Kong
• Keywords: Overset Grid, Shallow Water, Sinkage, TRIM

References

[1] Tuck E O. Sinkage and trim in shallow water of finite width[J]. Schiffstechnik, 1967, 14: 92-94.

[2] Wilson R V, Carrica P M, Stern F. Unsteady RANS simulation of a surface combatant with roll motion[J]. Comput Fluids 2006; 35: 501-24.

DOI: 10.1016/j.compfluid.2004.12.005

[3] Sato Y, Miyata H, Sato T. CFD simulation of 3-dimensional motion of a ship in waves: application to an advancing ship in heading waves[J]. Mar Sci Tec 1999; 4: 108-16.

DOI: 10.1007/s007730050013

[4] Gu M, Wu C S. CFD calculation for resistance of a ship moving near the critical speed in shallow water[J]. Journal of Ship Mechanics, 2005, 9(6): 40-47.

[5] Gu M, Wu C S, Jiang Y J et al. Numerical simulation on hydrodynamic characteristic of a trunk ship[J]. Journal of Ship Mechanics, 2003, 7(4): 15-20.

[6] Wu C S, Chen X, Sun L X et al. Numerical simulation of free ship model towed in still water[J]. Journal of Ship Mechanics, 2010, 14(8): 823-832(in Chinese).

[7] Steger J L, Dougherty F C, Benek JA. A Chimera grid scheme[J]. (1983).

[8] Wang F J. Computational Fluid Dynamics analyzer: software principle and application[M]. Tsinghua University Press, (2004).

[9] Jia X L, Yang Y S. The ship motion mathematical model: Modeling and identification modeling[M]. Dalian Maritime University press, 1999(in Chinese).

[10] Menter F R. Two-equation eddy-viscosity turbulence models for engineering applications[J]. AIAA journal, 1994, 32(8): 1598-1605.

DOI: 10.2514/3.12149

[11] Carrica P M, Wilson R V, Stern F. An unsteady single-phase level set method for viscous free surface flows[J]. International Journal for Numerical Methods in Fluids, 2007, 53(2): 229-256.

DOI: 10.1002/fld.1279

[12] Jiang T. Investigation of waves generated by ships in shallow water[C]. Proceeding of the 22nd Symposium on Naval Hydrodynamics, Washington DC: [s. n. ], 1998: 601-602.
