Characteristic Study on Parylene-C Film for Thermal Isolation on Chip

Abstract:

This paper deposited parylene-C films as thermal isolation filling material on the micro-trenches. The stress characteristic and the conformal coating characteristic of the parylene-C films were analyzed. The small stress and the good conformal coating are helpful for film material to decrease their influences on the mechanical and electric performances of the devices. The thermal isolation performance experiment was performed. The results showed that the temperature in the inside part of the testing device with a heating resistance is obviously higher than that in the outside part, separated by the thermal isolation structures coating with parylene films.

• Periodical: Applied Mechanics and Materials (Volumes 713-715)
• Pages: 2610-2613
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.713-715.2610
• Online since: January 2015
• Authors: Xu Ji*, Wei Wang, Xiang Bo Song, Hai Li Li, Xi Luo
• Keywords: On Chip, Parylene-C, Stress, Thermal Isolation

References

[1] C. M. Jha, et al., Thermal Isolation of Encapsulated MEMS Resonators, J. Microelectromech. Syst., vol. 17, 2008, pp.175-184.

[2] X. Liu, L. Li, A. J. Mason, Thermal Control Microsystem for Protein Characterization and Sensing, IEEE BioCAS Conf., Beijing China, Nov. (2009).

[3] Ji-song, H., et al., Fabrication of thermal-isolation structure for microheater elements applicable to fingerprint sensors. Sensors and Actuators A: Physical, 2002. 100(1): pp.114-122.

DOI: 10.1016/s0924-4247(02)00136-x

[4] Cham, J.G., et al., A New Multi-Site Probe Array with Monolithically Integrated Parylene Flexible Cable for Neural Prostheses. IEEE-EMBS (2005).

DOI: 10.1109/iembs.2005.1616146

[5] Ji Xu, Yu Huaiqiang, Huang Xianju, Lei Yinghua and Li Zhihong, Parylene film for sidewall passivation in SCREAM process., Sci China Ser E-Tech Sci, Vol. 52(2009): 2, pp.357-362.

DOI: 10.1007/s11431-008-0187-5

[6] Yinhua Lei, Wei Wang, Huaiqiang Yu, Yingcun Luo, Ting Li, Yufeng Jin, Haixia Zhang and Zhihong Li, A parylene-filled-trench technique for thermal isolation in silicon-based microdevices, J. Micromechanics and Microengineering, 2009, 19: 035013.

DOI: 10.1088/0960-1317/19/3/035013

[7] L. Li and A. J. Mason, Post-CMOS Parylene Packaging for On-chip Biosensor Arrays, IEEE Int. Conf. on Sensors, October (2010).

DOI: 10.1109/icsens.2010.5690397

[8] B. Lu, D. Zhu, D. Hinton, M. Humayun and YC Tai, Mesh-supported submicron parylene-C membranes for culturing retinal pigment epithelial cells, Biomedical Microdevices (2012), 14: 659-667.

DOI: 10.1007/s10544-012-9645-8

[9] B. Lu, S. Zheng, B. Q. Quach and Y. -C. Tai. A study of the autofluorescence of parylene materials for μTAS applications, Lab on a Chip, Vol. 10, pp.1826-1834, (2010).

DOI: 10.1039/b924855b
