Force Acquisition for Impact Tester

Abstract:

A force acquisition system for digital impact tester was investigated, in which structural design of bar-shaped elastic element, circuit design as well as static analysis were involved. Based on analysis of international requirements on the detection precision of digital impact tester, information concerning the precision of sensor parameters, sensors and adhesive was collected, and adhesion sites were settled through finite element analysis and optimization. Circuit design involved zero setting, temperature compensation, amplifying circuit, filter circuit and circuits to connect host computer. Loading calibration test was performed on sensors under static working condition. According to partial authoritative examination, the linearity was 0.06%, the repetitiveness was 0.01%, the retardation was 0.08%, and the sensitivity was 1.112. According to the examination conducted in some metrology institute, the total work error of impact in a digital impact tester adopting the above force acquisition system was 2% of the impact value of a standard specimen, which has already reached the precision level and met the design requirement..

• Periodical: Applied Mechanics and Materials (Volumes 716-717)
• Pages: 1026-1033
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.716-717.1026
• Online since: December 2014
• Authors: Guo Hui Han*, Tie Lin Shi
• Keywords: Amplifying Circuit, Digital Impact Tester, Force Acquisition System, Force Sensor

References

[1] Commission of Science, Technology and Industry for National Defense. GJB5372－2005 Dynamic-instrumentation impact test method for metal [S]., Beijing: Chinese Standard Press, Aug. 2005, p.8.

[2] Zhang Ruyi, Shen Guanlin and Li Zhaodi. Electric strain measurement and sensor [M]. Beijing: Tsinghua University Press, 1999, 43-59.

[3] State Administration of Quality Supervision, Inspection and Quarantine, PRC. GB/T3808-2002 Pendulum-type impact tester inspection [S]. Beijing: Chinese Standard Press , Oct. 2002, p.11.

[4] MA Binghui, LU Zeshheng. DEVELOPMENT OF MICRO FORCE SENSOR[J]. CHINESE JOURNAL OF MECHANICAL ENGINEERING. Vol. 42. 2005, p.228.

[5] C H EN Zhi2yong, Z HOU B I n , Z HA N G Rong. A Capacitive Force Transducer Structure with Improved Linearity[J], CHINESE JOURNAL OF SENSORS AND ACTUATORS. Vol . 21 　No. 4 Ap r . 2008, p.113.

[6] WU Xiumei, ZHAO L ianyu. Research of XXXynamo ic ca libra ting dev ice of force sensor[J], JOURNAL OF TIANJ IN UNIVERS ITY OF TECHNOLOGY, Vol. 23 No. 2Ap r. 2007, p.76.

[7] SHI Shuheng , WANG Bin , ZHU Jianqiang. Research of Key Technology for High Precision Capacitive Displacement Sensor[J], Instrument 　Technique 　and 　Sensor, 2007 No17, p.2.

[8] Tan J iubin Wang Fusheng, Study on Capacitance Displacement Sensor Based on Digital Synthesis Technology[J], CHINESE JOURNAL OF SENSORS AND ACTUATORS. Vol . 22 　No. 2 Ap r . 2001, p.181.

[9] Jia Bonian and Yu Pu. Sensor technology [M]. Southeast University Press, Nanjing. 1992, p.55.

[10] WANG Yong cheng, WANG Hong f ei, YA N G Cheng w u. Fus ion Algor ithm for A irborne Twin- sen sor Synchronous Angle On ly Tracking[J]. 　Con XXXroll and D ecision. Vo l. 20 No. 10, O ct. 2005, p.1144.

[11] Editorial board of Manual of Measuring and Testing Technology [S]. Manual of Measuring and Testing Technology [S]. China Measuring Press, Beijing. 1996, p.112.
