Establishment of the Dynamics Modal for the Fire-Suction Hydraulic Impactor

Abstract:

The drilling speed to shorten the drilling cycle plays a decisive role in drilling process.Using the fire-suction hydraulic impactor can achieve percussive-rotary drilling.The fire-suction hydraulic impactor can transform drilling fluid’s pressure energy into mechanical energy.Withing bit static pressure,rotational cutting and vertical impact loading,the way of rock breaking will be faster and more efficient.Using Newton's second law to establish the corresponding kinetic equations,motion equations and displacement equations.The comparison between parameters and measured data validated the correctness of the formulas,which provides a theoretical basis for the products to improve and seriation.

• Periodical: Applied Mechanics and Materials (Volumes 716-717)
• Pages: 743-746
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.716-717.743
• Online since: December 2014
• Authors: Ze Fu Bao*, Yuan Zhi Zhang, Jiang Ping Wang
• Keywords: Dynamics Modals, Hydraulic Impactor, Percussive-Rotary

References

[1] Chaoda Chen. The design of double action fire-suction hydraulic impactor  in deep well. [J]. Oil Field Equipment. 1999, 28(6): 43-46.

[2] Renjie Wang, Rongqing Jiang. Hydraulicpercussiverotary drilling. [M]. Beijng: Geological Public Press, (1988).

[3] Hongj iZhao. Study on the positive action of valve type hydraulic percussive drill. [J]. Oil Field Equipment. (1992).

[4] Rongqing Jiang. Introduction of hydraulic impact rotary drilling technology. [J]. Coal Geology and Exploration. (1980).

[5] Guomin Li. Double acting hydraulic impactor computational simulationmathematical model. [J]. Exploration Engineering. 1997, (4): 34-36.
