The Numerical Simulation of Reinforced Particle Stress Concentration in Al-Si Alloy Rolling

Abstract:

Aiming at the problem that temperature filed changes can lead to edge cracks emerge to Al-Si alloy 4004 in the process of hot rolling, in this paper, finite element model of temperature field variations in the process of rolling have been established by the method of finite element numerical simulation. The relationship between temperature field variations and edge crack defects has been analyzed. The results show that temperature field of rolled piece is gradient variations, low in the center and high in the edge, metal accumulation in the edge, leading to stress concentration and forming cracks source, resulting in edge cracks arising in edge of roller piece. Finally, the reliability and accuracy of the numerical simulation method have been verified by hot-rolled tests and tensile tests. All the studies provide ideas for theoretical analysis of temperature variation during hot rolling and have important significance on improve the quality of products.

• Periodical: Applied Mechanics and Materials (Volumes 719-720)
• Pages: 55-58
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.719-720.55
• Online since: January 2015
• Authors: Yan Ling Zhao*, Xue Song Yang, Zi Yan Yun, Hong Bo Wang, Guan Hong Xu
• Keywords: Al-Si Alloy, Edge Cracks, Hot Rolling, Temperature Filed

References

[1] Shen Z H. Heavy Non-ferrous Metal and Its Alloy Plate Strip Production. Beijing: Metallurgical Industry Press, (2011).

[2] Zhao S Q. Aluminum Alloy Hot Rolling and Strip Technology. Beijing: Metallurgical Industry Press, (2010).

[3] Duan R F. Aluminum Foil Production Technology. Beijing: Metallurgical Industry Press, (2010).

[4] Kang Y H, Liu Y H, He Y H. Deformation analysis of the hot rolling process of aluminum alloy. Journal of mechanical strength, 2012, 34(3): 455-458.

[5] Li X N, Xie M T. Deformation resistance model to test hot rolled aluminum alloy. CFHI Technology, 2012, 01: 63-65.

[6] Bai H, Meng X J, Chen L S, et al. Numerical simulation and failure analysis of rod hot rolling process using DEFORM. Journal of Hebei Polytechnic University (Natural Science Edition), 2008, 30(2): 1.

[7] Bai H. Numerical Simulation and Defection Infection of Rod Hot Rolling Process [Dissertation]. Tangshan: Hebei United University, (2008).

[8] Chen X F. Numerical Simulation of 1Cr13 Sheet Hot Rolling on Deform-3D[Dissertation]. Hangzhou: Zhejiang University of Technology, (2008).

[9] Lv R S, Dong W P, Chen J. Research on defection prediction of metal forming process. Die and Mould Technology, 2003, (3): 3-4.

[10] Deng S K. The Study of 2E12 Aluminum Alloy's Rolling Techniques and the Fatigue Performance[Dissertation]. Qinhuangdao: Yanshan University, (2007).
