Two 81-96 GHz Active Frequency Triplers MMIC

Abstract:

Two 81-96 GHz frequency triplers, one balanced and one single device, are implemented using a 0.10 μm GaAs pHEMT process. The EM simulation results show that the triplers perform a best conversion gain of -6.8 and -4.7 dB for the balanced and the single device, respectively. The conversion gain of the balanced tripler operating from 81 to 96 GHz is above -9.6 dB at 3dBm input power. The conversion gain of the single device operating from 81 to 96 GHz is above -8 dB at -0.5dBm input power. The fundamental and second harmonic suppression are as high as 30 dB over the whole operating frequency (81-96 GHz) for both circuits.

• Periodical: Applied Mechanics and Materials (Volumes 719-720)
• Pages: 875-880
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.719-720.875
• Online since: January 2015
• Authors: Hui He, Jian Zhang, Run Xi Zhang*, Chun Qi Shi, Tang Liu
• Keywords: Frequency Tripler, GaAs, HEMT, mm-Wave

References

[1] J.A. Wells, Faster than fiber: The future of Multi-Gb/s wireless, IEEE Microwave Magazine, vol. 10, No. 3, May 2009, pp.104-112.

DOI: 10.1109/mmm.2009.932081

[2] ECC Recommendation (05)07, Radio frequency channel arrangements for fixed service systems operating in the bands 71-76 GHz and 81-86 GHz, , October (2005).

[3] Y. Kawasaki, K. Shirakawa, Y. Ohashi, and T. Saito, 60-GHz monolithic oscillator using InGaP/InGaAs/GaAs HEMT technology, inIEEE MTT-S Int. Microwave Symp. Dig., vol. 2, May 1995, p.541–544.

DOI: 10.1109/mwsym.1995.406029

[4] T. Kashiwa, T. Ishida, T. Katoh, H. Kurusu, H. Hoshi, and Y. Mitsui, V-band high-power low phase noise monolithic oscillators and investigation of low phase-noise performance at high drain bias, IEEE Trans. Microwave Theory Tech., vol. 46, Oct. 1998, p.1559.

DOI: 10.1109/22.721165

[5] A. Kanda, T. Hirota, H. Okazaki, and M. Nakamae, An MMIC chip set for aV-band phase-locked local oscillator, inIEEE GaAs IC Symp. Dig., Nov. 1995, p.259–262.

DOI: 10.1109/gaas.1995.529007

[6] M. Funabashi, T. Inoue, K. Ohata, K. Maruhashi, K. Hosoya, M. Kuzuhara, K. Kanakawa, and Y. Kobayashi, A 60 GHz MMIC stabilized frequency source composed of a 30 GHz DRO and a doubler, in IEEE MTT-S Int. Microwave Symp. Dig., vol. 1, May 1995, p.71.

DOI: 10.1109/mwsym.1995.406095

[7] Z. Jian, B. Mingquan, D. Kuylenstierna, L. Szhau, and H. Zirath, Broadband Gm-boosted differential HBT doublers with transformer balun, IEEE Trans. Microw. Theory Tech., vol. 59, no. 11, Nov. 2011, p.2953–2960.

DOI: 10.1109/tmtt.2011.2166121

[8] Peter Stenger, Michael Sarantos, Edward Niehenke, Howard Fudem, Christopher Schwerdt, Fred Kuss, David Strack, George Henry, and John Masti, A Miniature, MMIC One Watt W-band Solid State Transmitter, 1997 IEEE MTT-S International Microwave Symposium Di-gest, pp.431-434.

DOI: 10.1109/mwsym.1997.602825

[9] E. W. Lin, Y. Kok, S. Dow, H. Wang, T. T. Chung, S. Lau, D. Okamuro, B.R. Allen, An Advanced Single-Chip Ka-Band Transceiver, 1996 IEEE MTT-S International Microwave Symposium Di-gest, pp.513-515.

DOI: 10.1109/mwsym.1996.510985

[10] U. Guttich, J. -M. Dieudonne, A Klaasen, H. Sledzik, K.E. Schmegner, U. Goebel, M. Bobeim, A Low Noise Heterodyne 89 Ghz MMIC Module for the Multifrequency Imaging Microwave Radiometer (MMIR), 1996 IEEE MTT-S International Microwave Symposium Di-gest, pp.21-24.

DOI: 10.1109/mwsym.1996.508454

[11] M. Sholley, R Alvarez, T. Leary, D. Renkowitz, S. Schell, L. Wendel, D. Cisneros, W. Brunner, B. Osg-ood, C. Gage, J. Alley, T. Cazares, P. Yocum, Wband Collision Avoidance Radar for Light Rail Application, 1996 IEEE MTT-S International Microwave Symposium Di-gest, pp.321-324.

DOI: 10.1109/mwsym.1996.508521

[12] M. Abbasi, M. Gavell, M. Ferndahl, and H. Zirath, An E -Band(71-76, 81-86 GHz) balanced frequency tripler for high-speed communications, in Proc. Microwave Conference, 2009. APMC 2009. Asia Pacific, dec. 2009, pp.1184-1187.

DOI: 10.1109/apmc.2009.5384416
