Application of Pro/Engineer in Mug Product Development and Mould Design

Abstract:

Pro/E was developed by the American company PTC CAD / CAM software, it is a new generation product modeling system with features as parametric design, three-dimensional solid model, feature-driven and single database. Pro/E software uses object-oriented unified database and parametric modeling technology, which has conceptual design, basic design and detailed design features,and provides excellent platforms for integrated manufacturing molds.Take Mug for example, the process of product modelling and mold design used by Pro/E software was introduced. The mold design cycle , the parting surface, the mold die space and the core was focused. The high efficiency characteristic of plastic mold design used by Pro/E was elaborated.

• Periodical: Applied Mechanics and Materials (Volume 722)
• Pages: 254-257
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.722.254
• Online since: December 2014
• Authors: Feng Chen*
• Keywords: 3D Modeling, Mould Design, Mug, Pro/E
