Discuss on Tunnel Design for High Speed Metro Line

Abstract:

When trains with high speed pass through the tunnel, there is pressure fluctuation in the tunnel which will cause discomfort of the driver and the passengers. Using unsteady one dimensional flow model, the aerodynamic effect caused by the train with speed of 120km/s running through the tunnel was calculated and analyzed. The results show that the routine tunnel size of Ф5.5m for metro lines can not meet the standard for comfort level. Instead, tunnels with inner diameters of 6.8m and 10.36m were recommended.

• Periodical: Applied Mechanics and Materials (Volume 723)
• Pages: 364-367
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.723.364
• Online since: January 2015
• Authors: Jiang Hong Kuang, Bin Yu
• Keywords: Aerodynamic Effect, High Speed Metro, Pressure Control, Pressure Fluctuation, Tunnel Design

References

[1] Xueyi Jin, Wenying Chen: Tunnel Ventilation and Aerodynamics (China Railway Vehicles Press, Beijing 1983).

[2] Feng Wang, Zhifang Yin, Kaiyuan He: ICPTT 2009, pp.910-921.

[3] Rudolf Bopp, Bernd Hagenah: J. Abroad Railway Vehicles, Vol. 49(2012), pp.10-17.

[4] Wei Wu, Huixiang Gao, Jinlong Peng: J. City Rapid Rail transit, Vol. 24(2011), pp.63-67.

[5] U.S. Department of Transportation. Subway Environmental Design Handbook Volume I ( U.S. Department of Transportation, 1976).
