Online Real-Time Detection Scheme Research on Precision of Filter Rod Circumference

Abstract:

Precision of filter rod circumference is an important performance index of the cigarette manufacturing. The forming mechanism of filter rod, equipment vibration and other interference factors all lead to fluctuations of precision of filter rod circumference which can affect the precision of the cigarette. The existing KDF2/3 filter rod making machine which has the characteristics of compact structure (small space dimension), high speed (300 m/min) and discrete control of precision of filter rod circumference is the core equipment of filter rod production. This paper puts forward four kinds of online real-time detection schemes on precision of filter rod circumference which are Aomeijia’s many groups of detectors scheme, Keyence’s contour detection scheme, high precision measuring diameter instrument detection scheme using multiple sets of KD series meter and the 360 degrees rotating survey meter. On the basis of extensive analysis and experimental validation, Aomeijia’s four-way diameter measuring instrument scheme is optimal. The scheme applies laser to non-contact high speed scan on key radial diameter size of filter rod which achieves 0.001mm high precision detection.

You might also be interested in these eBooks

Advanced Printing and Packaging Materials and Technologies

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 731)

Pages:

340-344

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.731.340

Citation:

Cite this paper

Online since:

January 2015

Authors:

Qian Ru Tian*, Bang Gui He, Zhi Long Wang

Keywords:

Detection Scheme, Laser Measurement, Online Real-Time Detection, Precision of Filter Rod Circumference

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Shisheng Wang, Yuanqiu Sang and Ye Zhang: Railway Computer Application. Vol. 14 (2005), pp.16-18.

Google Scholar

[2] Jianfeng Zhao and K. -H. Theisen: Modern Instruments. Vol. 16 (2010), pp.65-67.

Google Scholar

[3] Fang Li, Li Fu and Yang Fa: Mechanical Engineer. Vol. 9 (2008), pp.3-5.

Google Scholar

[4] Zhenmin Zou, Haiping Dong and Xiangfeng Xu: The Fourth Session of China's Online Analysis Instrument International BBS on Application and Development. Vol. 6 (2012), pp.399-420.

Google Scholar

[5] Wei Sun, Shengwei Su and Junqiang Ge: Hydroelectric Power. Vol. 38 (2012), pp.64-66.

Google Scholar

[6] Wenhua Huang: Tobacco Science. Vol. 12 (2012), pp.26-29.

Google Scholar

[7] Yonggang Zhang: Tobacco Science. Vol. 1 (2007), P. 30-32.

Google Scholar

[8] Lin Li, Bo Qian and Zhansheng Wang, China. 201020646444.X. (2011).

Google Scholar
