The Optimization of Group Panel-Type Radiator of Transformer

Abstract:

The author used CFD software to simulate when group panel-type radiator quantity, space, height of gooseneck have changed, how temperature distribute on the radiator. To obtain when group panel-type radiator quantity, space, height of gooseneck and other factors have changed, the laws of heat transfer efficiency changed and analyzed the reasons for emergence of such laws in theory. The optimal group of panel-type radiator improvement program is explored, to provide guidance for the practical application of engineering.

• Periodical: Applied Mechanics and Materials (Volume 733)
• Pages: 615-618
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.733.615
• Online since: February 2015
• Authors: Yi Ming Liang, Ming Ao, Da Ming Zhu, Qi Ming Zhao, Xiao Feng Cao, Zhi Peng Jiang
• Keywords: Numerical Simulation, Panel-Type Radiator, Transformer

References

[1] C. B. Zhang, Research on new Cooler System for Power Transformers [J], Transformer, Vol. 42 (2005), No. 8, p.1.

[2] X. Zhang, X. C. Wang and X. X. Guo, Flow Distribution and Cooling Capacity for each Channel of Panel-type Radiator CFD Analysis [J], Transformers, Vol. 48(2011), No. 3, p.1.

[3] Y. Tang, Y. Liu and C. J. Mu, Winding Hot Spot's Temperature Rising Calculations and Experimental Study on Transformer [J], Transformers, Vol . 38 (2001)No. 2, p.1.

[4] F. Cong, M .F. En, Y. Guo, Z. H. Dong and L. Y. Zhao, Numerical Simulation of Temperature Field on Oiland Air Cooled [J], Transformer, Vol . 40 (2003)No. 5, p.5.
