Research on the Vibration Condition On-Line Monitoring System for EHV Power Transformer

Abstract:

The paper introduces a design scheme for the Extra High Voltage (EHV) transformer condition on-line monitoring system, which is based on the collection and analysis of the transformer winding and core vibration signals. This system is composed of vibration acceleration signal sensors and the signal analyzing computer where the collected vibration signal is saved and processed. The analyzing computer can accomplish the missions of data acquisition control, data analysis and the historical data query. Vibration characteristic values of transformer winding and core include peak to peak value, spectrum, kurtosis, and the amplitude 100Hz component and its higher harmonic components. They are extracted, and the characteristic trend curves are drawn by data analysis, so that EHV transformer on-line monitoring and fault diagnosis are accomplished.

• Periodical: Applied Mechanics and Materials (Volume 734)
• Pages: 675-679
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.734.675
• Online since: February 2015
• Authors: Wan Qing Li*, Wei Wang, Le Ting Lin, Bei Min Xie, Ming Chao Xia, Ping Zhu Liu, Wei Ma
• Keywords: Fault Diagnosis, On-Line Monitoring, Power Transformer, Vibration
