Hybrid System for Photovoltaic Power Generation and Power Quality Control

Abstract:

In this paper, a hybrid system to carry out the function of photovoltaic power generation and power quality control simultaneously was proposed. The configuration and principle of the hybrid system were discussed firstly, and then the mathematical model of the hybrid system was presented. To realize the compound function, a deadbeat compound control strategy was proposed. In the compound control strategy, the calculation method of the reference signal is proposed to achieve reactive power and harmonic detection, active signal for grid-connected electricity generating and DC-side voltage maintaining; to improve the dynamic response and decrease the steady-state error of the hybrid system, deadbeat compound control method was proposed. The new hybrid system is implemented in a 10kVA prototype in the laboratory. Simulation and experimental results show that the proposed hybrid system can effectively stabilize photovoltaic power generation, reactive power compensation, and harmonic elimination.

• Periodical: Applied Mechanics and Materials (Volume 734)
• Pages: 759-770
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.734.759
• Online since: February 2015
• Authors: Wei Wei Song*
• Keywords: DC-Side Voltage Control, Deadbeat Compound Control Method, Harmonic Elimination, Photovoltaic Power Generation, Reactive Power Compensation

References

[1] Boico, F, and Lehman, B., Multiple-input maximum power point tracking algorithm for solar panels with reduced sensing circuitry for portable applications, Solar Energy, Volume 86, Issue 1, Jan. 2012, pp.463-475.

DOI: 10.1016/j.solener.2011.10.017

[2] Manoj Datta, Tomonobu Senjyu, Fuzzy Control of Distributed PV Inverters/Energy Storage Systems/Electric Vehicles for Frequency Regulation in a Large Power System, IEEE Trans. Smart Grid., vo. 4, no. 1, March, 2013, p.479–488.

DOI: 10.1109/tsg.2012.2237044

[3] Luo, A.; Shuai, Z.; Zhu, W.; Shen, Z.J.; Tu, C.; Design and application of a hybrid active power filter with injection circuit, IET Power Electronics, Volume 3, Issue 1, Jan. 2010, Pp. 54 – 64.

DOI: 10.1049/iet-pel.2008.0225

[4] Shunfu Lin, Diogo Salles, Walmir Freitas, Wilsun Xu , An Intelligent Control Strategy for Power Factor Compensation on Distorted Low Voltage Power Systems, IEEE Trans. Smart Grid., vo. 3, no. 3, Sep, 2012, p.1562–1570.

DOI: 10.1109/tsg.2012.2201756

[5] Shireen, W., Tao, L.: A DSP-based active power filter for low voltage distribution systems, IEEE Trans. Power Electron., vol. 78, no. 9, 2008, p.1561–1567.

DOI: 10.1016/j.epsr.2008.01.015

[6] Si-Hun Jo, SeoEun Son, Jung-Wook Park, On Improving Distortion Power Quality Index in Distributed Power Grids, IEEE Trans. Smart Grid., vo. 4, no. 1, March 2013, p.586–595.

DOI: 10.1109/tsg.2012.2222943

[7] Carlos Frederico M. Almeida, Nelson Kagan, Harmonic State Estimation Through Optimal Monitoring Systems, IEEE Trans. Smart Grid., vo. 4, no. 1, March 2013, p.467–478.

DOI: 10.1109/tsg.2012.2235472

[8] L. Yan and B. Lehman, A capacitor modeling method for integrated magnetic components in DC/DC converters, IEEE Transactions on Power Electronics, vol. 20, no. 5, September 2005, pp.987-996.

DOI: 10.1109/tpel.2005.854018

[9] A. Khaligh, J. R. Wells, P. L. Chapman, and P. T. Krein, Dead-time distortion in generalized selective harmonic control, IEEE Trans. Power Electron., vol. 23, no. 3, May 2009, p.1511–1517.

DOI: 10.1109/tpel.2008.921162

[10] A. D. le Roux, H. D. T. Mouton, and H. Akagi, DFT-based repetitive control of a series active filter integrated with a 12-pulse diode rectifier, IEEE Trans. Power Electron., vol. 24, no. 6, Jun. 2009, p.1515–1521.

DOI: 10.1109/tpel.2009.2015882

[11] Morris Brenna, Federica Foiadelli, Analysis of the Filters Installed in the Interconnection Points between Different Railway Supply Systems, IEEE Trans. Smart Grid., vo. 3, no. 1, March 2012, p.551–558.

DOI: 10.1109/tsg.2011.2162860

[12] K.K. Ts, M.T. Ho, H. Chung. A novel maximum power point tracker for PV panels using switching frequency modulation,. IEEE Trans. Power Electron. vol. 17, Nov. 2002, Pp. 980-989.

DOI: 10.1109/tpel.2002.805594
