Study on the Influence Factors of Dry Hollow Parallel Reactor Loss

Abstract:

Reactor individual branch loss mutation is one of the important reasons leading to local temperature too high. In order to explore process deviation for dry type hollow shunt reactor loss amplification effect, this paper is establish a loss calculation model of dry-type air-core reactor as the tool, Comparative analysis relationship between the four common types of process deviation and the local branch loss. Calculation results show that the number of turns deviation are the main factor influencing the reactor partial loss, So the reactor production winding process should strengthen the control of the number of turns deviation.

• Periodical: Applied Mechanics and Materials (Volume 734)
• Pages: 887-892
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.734.887
• Online since: February 2015
• Authors: Xiao Bing Guo*, Xiang Yu Tan, Yong Hong Wang, Yan Wang, Kun Ming Zhao, Jie Zhang
• Keywords: Branch Loss, Dry-Type Air-Core Shunt Reactor, Process Deviation, Relative Variation

References

[1] Zhigang Cui . Dry type hollow shunt reactor is the cause of the problem [J]. transformer. 2012, 49(3): 61-63. In Chinese.

[2] Baixiong Yang. Dry type hollow shunt reactor fault analysis and Suggestions for improvement[J]. North China electric power technology . 1995, 33. In Chinese.

[3] Saocheng Jiang, Ruihai Dai, Xiaobo Xia. Dry-type air-core reactor turn-to-turn insula-tion detection principle and experimental analysis[J]. High voltage electrical. 2011, 47(6): 7-71. In Chinese.

[4] Jichao Yang, Yanzhen Zhao, Xikui Ma. An Online Detection System for Inter-Turn Short Circuit Faults in Dry-Type Air-Core Reactor Based on LabVIEW[J]. Industrial Electronics, IEEE Transactions on, 2000, 47(5): 1078-1084.

DOI: 10.1109/icems.2011.6073637

[5] Yaolong Wang. Dry type hollow shunt reactor several damage cause analysis. Electrical technology[J]. 2012, (7): 55-57. In Chinese.

[6] Yangling Li, Junbiao Wan, Ying Hang. 10 kv dry-type air-core series reactor failure cause analysis[J]. Power capacitor and the reactive power compensation. 2011, 32(3): 58-61. In Chinese.

[7] Junjie Miao, Qingli Jiang. 500 kV substations of 35 kV dry-type reactor failure analysis[J]. Power capacitor and the reactive power compensation. 2012 , 33(4): 65-69. In Chinese.
