The Design of Parallel IGBT Modular for Modularized Wind Power Converter

Abstract:

Aiming at meeting the requirement of modularization for megawatt wind power converter, the paralleling structure of IGBT modules was designed. Fast transient response and current sharing capabilities of the paralleled IGBT modules were regarded as the main research object, the drive circuit and adapter plate was also designed. utilizing the new type of protection circuit on the adapter plate to ensure reliability of the paralleled IGBT modules. As one of the most promising technologies, Digital drive technology was applied as the conception of the driver, and the core of the driver is FPGA and A/D sampling circuit. Using digital driver had the advantages of good consistency pulse parameters, flexible software programming and high anti-jamming ability. The current equalization among the IGBT modules was verified by means of the field test. Based on the experiment, the characteristics of balancing parallel IGBTs' currents were better than previous designs. It is concluded that the whole design of the system was reasonable and can meet the demands of the engineering applications.

• Periodical: Applied Mechanics and Materials (Volume 734)
• Pages: 873-876
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.734.873
• Online since: February 2015
• Authors: Xiao Jin Fu*, Chun Lan Que, Shuai Zhang, En Xing Yang, Hang Ye
• Keywords: Current Sharing Capabilities, Digital Drive Technology, Fast Transient Response, Parallel IGBT Module, Wind Power Converter

References

[1] Chen Bingsen, Hu Lihua. General Situation and Prospect of Wind Power in China[J]. POWER SYSTEM TECHNOLOGY, 2008, 32(S2): 272-275.

[2] Sun Qiang, Wang Xueru, Cao Yuelong. Study of current balances of IGBT in paralleling[J]. Electric Engineering, 2004 , 09: 84-86+89.

[3] LUNIEWSKI P, JANSEN U. Benefits of system-oriented IGBT module design for high power inverters[A]. Proceedings of the Power Electronics and Applications [C], Aalborg, Denmark , (2007).

DOI: 10.1109/epe.2007.4417527

[4] BORTIS D, STEINER P, BIELA J, et al. Double-stage gate drive circuit for parallel connected IGBT modules[J]. Dielectrics and Electrical Insulation, IEEE Transactions on, 2009, 16(4): 1020-1027.

DOI: 10.1109/tdei.2009.5211849

[5] GEN C, YONG W, XU C, et al. Adaptive digital drive for high power and voltage IGBT in multi-MW wind power converter[A]. Proceedings of the Power Electronics and Motion Control Conference (IPEMC) [C], Harbin, CHINA, (2012).

DOI: 10.1109/ipemc.2012.6259033

[6] HANDT K, KNORR R, ECKERT M, et al. Fully digitised, quasi-continuous working gate-drive unit for 1200V-IGBT[A]. Proceedings of the Power Electronics and Applications (EPE) [C], Lille, France, (2013).

DOI: 10.1109/epe.2013.6634605

[7] Yuliang Yang. Numerical Simulation on the Water-cooled Heat Sink for High-power Semiconductor[D]. He Bei: North China Electric Power University, (2012).
