Millimeter Wave Characterization of Wire Bond Transitions for W-Band Electromagnetic Sensor

Abstract:

This paper presents millimeter wave characterization and models of various wire bond transitions between chip’s ground-signal-ground pad (GSG) and microstrip (MS), include single-wire-nomatch MS-GSG transition, double-wire-nomatch MS-GSG, single-wire-match MS-GSG transition, and double-wire-match MS-GSG transition. It also presents the 3D full-wave electromagnetic simulation. Analysis results show that the double-wire-match MS-GSG transition’s characteristic is better than other three transitions in the whole W band. The accurate extracted parameter values are used for the lumped equivalent circuit model, whose simulation results are good with the full wave simulation results. The error between lumped equivalent circuit and full-wave models is of the order of ±0.2dB for S11 and S21 in the frequency range 75 - 105GHz. The proposed lumped equivalent circuit is suitable to be implemented in commercial microwave CAD tools for the electromagnetic sensor designing.

• Periodical: Applied Mechanics and Materials (Volumes 738-739)
• Pages: 103-106
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.738-739.103
• Online since: March 2015
• Authors: Yong Fang, Bao Qing Zeng*, Wen Tao Zhang, Pu Wang
• Keywords: Electromagnetic Sensor, Millimeter Wave, MS-GSG, W-Band, Wire Bond

References

[1] JuHwan Lim, DaeHan Kwon, Jae-Sung Rieh, Soo-Won Kim, and SungWoo Hwang: IEEE Trans. on Advanced Packaging. Vol. 28, (2005), p.772.

DOI: 10.1109/tadvp.2005.853554

[2] F. Alimenti, P. Mezzanotte, L. Roselli, and R. Sorrentino: IEEE Trans. Microw. Theory Tech. Vol. 49 (2001), p.142.

[3] F. Alimenti, P. Mezzanotte, L. Roselli, R. Sorrentino: IEEE MTT-S International Vol. 2 (1999), p.633.

[4] Hai-Young Lee: IEEE Microwave and Guided Wave Letters Vol. 4 (1994), p.265.

[5] Hao-Geng Lin, Tian-Wei Huang, Ruey-Beei Wu, and Chien-Min Lin: Asia-Pacific Microwave Conference Proceedings, Vol. (2005).

DOI: 10.1109/apmc.2005.1606252

[6] Thanh Vinh Dinh, Daniel Pasquet, Julien Pagazani, Gaëlle Lissorgues, and Pierre Nicole: Semiconductor Conference Dresden-Grenoble, (2013), p.1.

DOI: 10.1109/iscdg.2013.6656302

[7] Ansoft High-Frequency Structure Simulator (HFSS) User Manual, Ansoft, Inc., Pittsburgh, PA.

[8] Shiwang Jia, Xiaomei Huang, Zhonghai Zhang: Radio Engineering Vol. 40(2010), p.57, In Chinese.
