The Assembly Error Detection of Automotive Airbag Based on Machine Vision

Abstract:

Based on the principle of machine vision technology, we designed a methodto detect the outline dimensions of automotive airbag quickly and accurately. We Used CCD camera obtain the airbag image, through the image processing method ofsmooth filtering andgray-scale transformationto complete pre-processing, finally applied Canny edge detection operator to extract the boundary of the airbag contour features,and then took the template matching methodto detect assemble error of the airbag image whether meet the requirement.The results show that the detection method have a higher precision, and the time is very short, it can improve the sampled positioningerror detection for the all checks image recognition detection, suitable for application in real-time online detection of airbag assembly line.

You might also be interested in these eBooks

Sensors, Measurement, Intelligent Materials and Technologies III

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 738-739)

Pages:

694-698

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.738-739.694

Citation:

Cite this paper

Online since:

March 2015

Authors:

Xiao Dong Wang*, Qi Liu, Wei Zhang

Keywords:

Assembly Error, Edge Detection, Machine Vision, Safety Airbag, Template Matching
