The Design of the Loss-in-Weight Weighing Controller

Abstract:

In order to achieve higher precision, reliability and stability, lower cost and power consumption, friendly user interface and network functions, loss-in-weight weighing Controller based on ARM9 and Windows CE is designed for controlling dynamic real time batching equipment. This paper first introduces the working principle and architecture of the embedded Controller, then explains hardware system component and design of software system of the Controller, developed on Platform Builder 5.0. The paper pays more attention on the application layer development. Subfuctions of application software are introduced and working flow chart of main modules is given. Double incremental PID algorithm used by the system is presented to achieve the highest accuracy in the shortest possible time. The high precision 0.1% can be achieved, and Controller products are widely used in the metallurgy, chemical industry.

• Periodical: Applied Mechanics and Materials (Volume 740)
• Pages: 283-288
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.740.283
• Online since: March 2015
• Authors: Li Rong*
• Keywords: ARM, Batching Equipment, Digital PID Algorithm, Loss-In-Weight Weighing Controller, Windows CE

References

[1] Haijun Liang, The Application of Loss-in-weigh Scales in Industrial Production, Science and Technology Communication, Vol. 7(2011), p.166.

[2] Xiaoqing Quan , The Development and Analysis of the Market of Loss-in-weight Scales in China, China Measurement , No. 1 (2013) , pp.69-71.

[3] Yongbin Gao, Routine Maintenance and Troubleshooting of Loss-in-weigh Scales, Synthetic Technology and Application, Vol, 28 No. 3(2013), pp.51-54.

[4] Fitzpatrick, J. An Interview with Steve Furber. Communications of the ACM. 2011, 54 (5): 34.

[5] Luxiang Luan, Application of 32 Bit Embedded System in the Industrial Control, Machinery Design & Manufacture, No. 4(2010), pp.87-89.

[6] Zhongjian He, Windows CE Embedded Operating System, University of Beijing Aeronautics and Astronautics Press(2006).

[7] Binghong Yu, Baoan Li, Gongxun Shen, WINCE Customization Based on ARM, Modern Electronic Technology, Vol. 273, No. 10( 2008 ), pp.73-75.

[8] Yaping Zhao, Feng Wang, The Discussion of Calculation Principles and Methods of Loss-in-weigh Scales, http: /www. baidu. com.

[9] Xie Fang, HongguoYang, The Analysis and Design of Digit PID Algorithm Improvement, Journal of JIAOZUO Teachers College, Vol. 26, No. 2(2010), pp.77-80.

[10] Jian Chao, The Development Status and Trend of Plastic Industry in China, China Packaging, 2013-12-20(1).
