Optimal Design of Runner for Shell of Mobile Telephone Based on Moldflow Software

Abstract:

The runner balance of upper cover and back cover of mobile telephone was optimized in view of the runner imbalance of different mould multi-cavity in the design of plastic injection mold by means of Moldflow software. The results that the fill time of the back cover of mobile telephone is 0.8858s, that of the upper cover of mobile telephone is 0.8588s, the imbalance rate is 3.1%. The optimized runner size is φ3.739mma and φ1.666mm while the runner size is φ3mm before optimization. The gate location of V/P switch point is 29.85Mpa and is close to the target pressure 30Mpa, the pressure in the distribution is uniform.

• Periodical: Applied Mechanics and Materials (Volume 741)
• Pages: 191-194
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.741.191
• Online since: March 2015
• Authors: Guo Gong Sun*, Chang Hua Liu, Qiang Li
• Keywords: Mobile Telephone Cover, Moldflow, Runner Balance, V/P Switch Point

References

[1] Lu Ning: Practical design of injection mold, edited by China Light Industry Press, Beijing (2003).

[2] Li Zheng guang: Polyvinyl Chloride. Vol. 3(2008), P. 23.

[3] Zhong Pei Si, Zhao Guo Qiang, Zhang Rui kan. Optimal Design of Runner Balance for Plastic Injection Mold Based on MPI[J]. Coal Mine Machinery. Vol. 12(2006), P. 19.

[4] Zhou Da Lu, He Bai lin, Li Shu zhen. Plastics. Vol. 36(2007), P. 95.

[5] Shan Yan, Wang bei, Wang gang: Basis of Mold Technical Analysis with Moldflow software, edited by Tsinghua University Press, Beijing(2005).
