A Research on the Real-Time 3-D Imaging Technology and Multi-View Control Interface Design for the Attitude Motion Simulator

Abstract:

In order to have a real-time 3-D imaging of the attitude motion simulator model and to design a multiple views interface in the display and control software of the attitude motion simulator, Firstly, 3D Model of the attitude motion simulator model has been transformed to STL file; Secondly, the functions on the VC++6.0 platform have been written to read the STL file, and 3-D Image display from STL file has been realized by the programming technique of the triangle mesh renderingin OpenGL.Meanwhile, the real-time synchronization has been realized between the 3-D Imageand real angle of attitude motion simulator model.Finally, in order to meet the demands ofcontrol and display software, a multiview control interface in which a real-time data interchange amongthe multiple views is designed.

• Periodical: Applied Mechanics and Materials (Volume 741)
• Pages: 363-367
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.741.363
• Online since: March 2015
• Authors: Dong Ji*, Rui Jie Ji, Hua Pei Wang, Hai Bo Zhang, Xiao Jie Tong
• Keywords: 3-D Imaging Technology, Multiview Control Interface, OpenGL, STL File

References

[1] ALVERSON G, EULISSE G, MUZAFFAR, etal. A high-performance 2D and 3D visualization system[J]. Nuclear Instruments & Methods in Physics.

[2] Research(A), 2004, 534(11): 143-146TheKhronosGroup. OpenGLOverview. http: /www. opengl. org/about/overview/#1, 2009. 5. 26.

[3] Qiao Lin, Fei Guang-zheng. OpenGL Program Design. Beijing, Tsinghua University Press, (2000).
