A Method for Controlling the Permanent Magnet Linear Motor with the Counterweight by Pneumatic Cylinder

Abstract:

In the control model of the permanent magnet linear motor (PMLM), if the pneumatic cylinder is used to balance the weight, the pressure dynamic variation of both suction chamber and discharge chamber can affect the load force of model. The dynamic model of pneumatic cylinder is analyzed, and the equation of impedimental force caused by the single acting pneumatic cylinder is given out. With the combination of PMLM model, the system’s kinetics equation is established. A modified 3-tier composite control structure based on nonlinear force observer is put forward. The nonlinear part of the system is compensated effectively. The the experiment results demonstrate the practical applicability and efficiency of the proposed method.

• Periodical: Applied Mechanics and Materials (Volume 742)
• Pages: 477-484
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.742.477
• Online since: March 2015
• Authors: Sheng Chen, Dong Biao Zhao*, Yang Wei Wang
• Keywords: 3-Tier Composite Control, Impedimental Force, Linear Motor, Pneumatic Cylinder

References

[1] K.K. Tan, T.H. Lee, S. Huang. Precision Motion Control Design and Implementation. second ed., Springer, London, (2008).

[2] Z.J. Li, C.Y. Liu, F.W. Meng, et al. Precision motion control of permanent magnet linear synchronous motor servo system based on an integrated controller with inertia variation compensation. Proceedings of the Institution of Mechanical Engineers, Part C: Journal of Mechanical Engineering Science, 227 (2013).

DOI: 10.1177/0954406212459698

[3] H.W. Chow , C.C. Norbert. Disturbance and Response Time Improvement of Submicrometer Precision Linear Motion System by Using Modified Disturbance Compensator and Internal Model Reference Controls, IEEE Transactions on Industrial Electronics, 60 (2013).

DOI: 10.1109/tie.2012.2185015

[4] S. Cheng, C.W. Li. Fuzzy PDFF-IIR controller for PMSM drive systems[J]. Control Engineering Practice, 19 (2011) 828-835.

DOI: 10.1016/j.conengprac.2011.04.011

[5] G. Belforte, S. Mauro, G. Mattiazzo. A method for increasing the dynamic performance of pneumatic servo systems with digital valves. Mechatronics, 14 (2004) 1105-1120.

DOI: 10.1016/j.mechatronics.2004.06.006

[6] C.H. Lu, Y.R. Hwang, Y.T. Shen. Backstepping sliding-mode control for a pneumatic control system. Proceedings of the Institution of Mechanical Engineers, Part I: Journal of Systems and Control Engineering, 224 (2010) 763-770.

DOI: 10.1243/09596518jsce992

[7] Y.H. Bai, X.N. Li. Improvement of the State Feedback Control for Pneumatic Position Servo System. Journal of Mechanical Engineering, 45 (2009) 101-105.

DOI: 10.3901/jme.2009.08.101

[8] C. de wit Canudas, H. Olsson, K.J. Astrom, et al. A new model for control of systems with friction. IEEE Transactions on Automatic Control, 40 (1995) 419-425.

DOI: 10.1109/9.376053

[9] Beater P. Pneumatic Drives: System Design, Modelling and Control. Springer-Verlag, Berlin Heidelberg, (2007).

[10] BS ISO 6358-1: 2013. Pneumatic fluid power — Determination of flow-rate characteristics of components using compressible fluids — Part 1: General rules and test methods for steady-state flow. 22-23.

DOI: 10.3403/30227645u

[11] H. Olsson. Control Systems with Friction. PhD Thesis, Lund Institute of Technology, Sweden, (1996).

[12] W. Susanto, R. Babuska, F. Liefhebber, et al. Adaptive Friction Compensation: Application to a Robotic Manipulator. In: Proceedings of the 17th World Congress for the International Federation of Automatic Control, Seoul, Korea, 6 July -11 July 2008, p.2020.

[13] Y. Wang, ZH.H. Xiong, H. Ding. Friction compensation design based on state observer and adaptive law for high-accuracy positioning system. Progress in Natural Science, 16 (2006) 147-152.

DOI: 10.1080/10020070612331343206
