Free Vibration Analysis of Two Types of Conical Springs

Abstract:

In this paper, a free vibration analysis of two types of conical springs is presented by using ANSYS software. The APDL programming is employed for the finite element modeling. Two types of conical springs, such as constant pitch and constant pitch angle, which are not distinguished in previous researches, are investigated. The results suggest that the two types of conical springs should be distinguishable in the dynamic applications.

• Periodical: Applied Mechanics and Materials (Volumes 744-746)
• Pages: 157-161
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.744-746.157
• Online since: March 2015
• Authors: Guang Can Jin*, Hao Liu
• Keywords: Conical Springs, Constant Pitch, Constant Pitch Angle, Free Vibration

References

[1] Y. Lin, A. P. Pisano: Journal of Applied Mechanics. Vol. 54 (1987), pp.910-916.

[2] K. Nagaya, S. Takeda, Y. Nakata: International Journal of Numerical Methods in Engineering. Vol. 23 (1986), pp.1081-1099.

[3] M. H. Wu, W. Y. Hsu: Journal of Sound and Vibration. Vol. 214 (1998), pp.17-28.

[4] V. Yildirim, N. Ince: Journal of Sound and Vibration. Vol. 204 (1997), pp.311-329.

[5] V. Yildirim: Journal of Applied Mechanics. Vol. 65 (1998), pp.157-163.

[6] V. Yildirim: Communications in Numerical Methods in Engineering. Vol. 20 (2004), pp.207-227.

[7] W. Busool, M. Eisenberger: Journal of Vibration and Acoustics. Vol. 124 (2002), pp.397-409.

[8] K. Girgin: Journal of Sound and Vibration. Vol. 297 (2006), pp.931-945.

[9] J. Lee: Journal of Sound and Vibration. Vol. 302 (2007), pp.185-196.

[10] J. Lee : Journal of Sound and Vibration Vol. 305 (2007), pp.543-551.

[11] Y. H. Zhang, H. H. Liu and D. Wang: Spring manual (China machine press, Beijing 1997).

[12] Information on http: /www. ansys. com.
