Numerical Simulation for Predicting Fire Behavior of Axially Loaded Circular Concrete Filled Steel Tubular Columns

Abstract:

The present study investigates the behavior of axial loaded circular concrete filled hollow steel section (CFHSS) columns. A nonlinear finite element model using ABAQUS program was developed to investigate the fire behavior of the inspected columns from previous fire tests. The study variables include column dimensions, steel section wall thickness, concrete strength, concrete types (plain or reinforced), and fire protection thickness. The comparison indicated that the results obtained from the model were within acceptable limit of accuracy of 15%. A sensitivity study was carried out to investigate the influence of the output of the numerical model including the Poisson’s ratio of concrete, thermal conductance at the steel-concrete interface, frictional contact at steel-concrete interface, and imperfection buckling of columns. Based on the sensitivity analysis, several modelling suggestions were given in this paper which will be beneficial for further study.

• Periodical: Applied Mechanics and Materials (Volumes 752-753)
• Pages: 507-512
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.752-753.507
• Online since: April 2015
• Authors: Ahmad Nurfaidhi Rizalman*, Mahmood Md Tahir, Shahrin Mohammad, Arizu Sulaiman
• Keywords: Concrete Filled Hollow Steel Section Columns, Finite Element Analysis (FEA), Fire Resistance Rating

References

[1] L. Twilt, R. Hass, W. Klingsch, M. Edwards and D. Dutta, Design Guide for Structural Hollow Sections Exposed to Fire, second ed., CIDECT, Germany, (1996).

[2] X.L. Zhao, L.H. Han and H. Lu, Concrete-filled Tubular Members and Connections, Spon Press, (2010).

[3] T.T. Lie and M. Chabot, A Method to Predict the Fire Resistance of Circular Concrete Filled Hollow Steel Columns, J. Fire Prot. Eng. 2 (4) (1992) 111-126.

DOI: 10.1177/104239159000200402

[4] T.T. Lie and V.K.R. Kodur, Fire Resistance of Steel Columns Filled with Bar-reinforced Concrete, J. Struct. Eng. 122 (1) (1996) 30-36.

DOI: 10.1061/(asce)0733-9445(1996)122:1(30)

[5] J. Ding and Y.C. Wang, Realistic Modelling of Thermal and Structural Behaviour of Unprotected Concrete Filled Tubular Columns in Fire, J. Constr. Steel Res. 64 (10) (2008) 1086-1102.

DOI: 10.1016/j.jcsr.2007.09.014

[6] CEN. EN 1993-1-2, Eurocode 3: Design of Steel Structures – Part 1-2: General Rules – Structural Fire Design. Comité Européen de Normalisation, Belgium, (2005).

DOI: 10.1002/9783433601570.oth1

[7] T. Lie. Fire Resistance of Circular Steel Columns Filled with Bar-Reinforced Concrete, J. Struct. Eng. 120 (5) (1994) 1489-1509.

DOI: 10.1061/(asce)0733-9445(1994)120:5(1489)

[8] S. Hong and A.H. Varma, Analytical Modelling of the Standard Fire Behaviour of Loaded CFT Columns, J. Constr. Steel Res. 65 (1) (2009) 54-69.

DOI: 10.1016/j.jcsr.2008.04.008

[9] A. Espinos, M.L. Romero and A. Hospitale, Advanced Moded for Predicting the Fire Response of Concrete Filled Tubular Columns, J. Constr. Steel Res. 66 (8-9) (2010) 1030-1046.

DOI: 10.1016/j.jcsr.2010.03.002

[10] ASTM. Standard test methods for fire tests of building construction and materials, E119. American Society for Testing and Materials, W. Conshohocken, (2003).

[11] ISO (International Standards Organization). ISO-834: Fire Resistance Tests - Elements of Building Construction. International Standards Organization, Geneva, Switzerland, (1980).

[12] T.T. Lie and M. Chabot, Experimental Studies on the Fire Resistance of Hollow Steel Columns Filled with Plain Concrete, National Research Council Canada, Internal Report No. 611 (1992).

[13] M. Chabot and T.T. Lie, Experimental Studies on the Fire Resistance of Hollow Steel Columns Filled with Bar-reinforced Concrete, National Research Council Canada, Internal Report No. 628 (1992).

[14] L.H. Han, X.L. Zhao, Y.F. Yang and J.B. Feng, Experimental Study and Calculation of Fire Resistance of Concrete-filled Hollow Steel Columns, J. Struct. Eng. 129 (2003) 346-356.

DOI: 10.1061/(asce)0733-9445(2003)129:3(346)

[15] W.Y. Gao, J.G. Dai, J.G. Teng and G.M. Chen, Finite Element Modelling of Reinforced Concrete Beams Exposed to Fire, Eng. Struct. 52 (2013) 488-501.

DOI: 10.1016/j.engstruct.2013.03.017

[16] H. Lu, X.L. Zhao and L.H. Han, Fire Behaviour of High Strength Self-Consolidating Concrete Filled Steel Tubular Stub Columns, J. Constr. Steel Res. 65 (2009) 1995-(2010).

DOI: 10.1016/j.jcsr.2009.06.013
