The Parametric Drawing System of Shaft Based on Feature

Abstract:

The paper mainly studied the parametric drawing system of shaft based on feature. Firstly, the shaft was classified, and its characteristic was analyzed. Then, the special menu and image block menu of the system were designed in AutoCAD. And a friendly-interface parametric drawing system of shaft was built with geometry sculpts technology, object-oriented technology and parametric design technology, based on the platform of AutoCAD, with the development tool of Object ARX. It implemented the drawing of hardware working drawing of shaft according to the selected proportion, and improved the efficiency of the shaft design.Overview of shaftShaft is one of the main parts of machinery, depending on the axis shape; shaft can be divided into two categories: direct axis and crank shaft. According to the different load of the nature, direct axis can be divided into three types: spindle, drive shaft and the shaft. According to different shape, direct axis can be divided into two kinds: optical axis and stepped shaft. Optical axis has the following characteristics: simple shape, easy processing, less stress concentration source, optical axis is mainly used for drive shaft; Stepped shaft, in contrast to the optical axis. It is often used in the shaft. The classification of the shaft can be clearly said to use figure 1. In addition, there are some special shaft, such as the camshaft and wire soft shaft, etc.Fig. 1 Classification of the shaftOn the basis of the characteristics, the shaft information model can be considered. Usually a mechanical parts contains numerous features, shape features are the most important characteristics of these, which is the carrier of other information. We can decompose research the shape feature and think that some auxiliary features and the main features combined shape feature of axis, the main characteristics of the spatial position is adjacency relations; Auxiliary features is attached to a primary, auxiliary features can be attached to the main outline of the surface or end^[1].Combining with the actual situation of this system, we analyze the features of commonly used straight shaft parts; we obtained the shape of the feature classification results as shown in table1.Table 1 Straight shaft parts classification of shape feature

• Periodical: Applied Mechanics and Materials (Volume 757)
• Pages: 153-157
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.757.153
• Online since: April 2015
• Authors: Zhi Xue Sun*, Yang Zhang
• Keywords: Characteristic Analysis, Object Arx, Parameterized Design, Shaft

References

[1] Yufeng Li. Researching and Developing a shaft CAD system Based on Feature and Database [D]. xi, an: Xian University of Architecture and Technology, 2002: 7-19.

[2] Fujun Wang, Zhimin Zhang, Shiwei Zhang. Under the environment of AutoCAD2000 C/Visual C++application development tutorial [M]. Beijing: Beijing Hope Electronic Press, 2008: 3-4.

[3] Gang Yang. The CAD style of the sheet metal piece and its expansion [D]. xi, an: Xian University of Architecture and Technology, 2005: 20-21.

[4] Xuechun Liang, Deming Song. AutoCAD2002 secondary development technology guide [M]. Beijing: Tsinghua University Press, 2001: 111-116.

[5] Jing-xia Ge, Hong-bin Cui. Research and development of parametric drawing system for column CAD [J]. Machinery Design & Manufacture, 2006(01): 75-77.

[6] Kezhen Yang, Guangyun Cheng. Fundamentals of mechanical design (Fifth Edition) [M]. Beijing: China Higher Education Press, 2011: 244-251.

[7] Haixia Chen, Guangde Gao. Grill Parameterization Design Based on ObjectARX and Visual C++ [J]. Journal of China Three Gorges University (Natural Sciences), 2006, 28(01): 61-64.

[8] Huilan Zhou , Xinjian Zhou . Development and Realization of CAD System of Simple Supported Axis about Stress Designing and Auto-modifying [J]. Journal of East China Jiaotong University, 2007, 24 (05): 53-56.

[9] Huijun Yi , Jingnong Zhong . Study the CAD system of axle parts in reducer [J]. journal of Hunan University（Natural Science Edition）, 2003, 30 (03): 41-43, 61.

[10] Xiushi Pan, Junfang Ni. Study on Shaft Parametric Design System Based on Solid Edge [J]. journal of Soochow University(Engineering Science Edition), 2012, 32(03): 21-25.
