Stitch Bonding Strength of Cu Wire on AuAg/Pd/Ni Preplated Cu Leadframes: Influence of AuAg Thickness

Abstract:

Copper (Cu) wire bonding on the pre-plated leadframes with Ni/Pd/AuAg plating has been applied extensively in the semiconductor industry for the interconnection of integrated-circuit (IC) packaging due to the lower material cost of Cu and its excellent electrical properties. Furthermore, the Cu wire bonding on the preplated leadframe has advantages, such as the tin whisker prevention and the robust package for automotive application. Nevertheless, a stitch bondability of Cu wire-preplated leadframe is facing several challenges, such as the Cu oxidation, the high hardness of Cu wire and the very thin AuAg plating on the leadframes. This paper discusses the effect of AuAg plating thickness in roughened pre-plated leadframe on the stitch bonding of Cu wires with the leadframe. The stitch bonding integrity was assessed using Dage 4000 shear/pull tool at a key wire bond responses of stitch pull at time zero (T₀). Results show that the stitch pull strength of the Cu-leadframe stitch bonding increases with the increase thickness of AuAg layer. FESEM images of the stitch bonding between the Cu wires and the pre-plated leadframes of different AuAg plating thickness did not show any defect in microstructures, thus it suggests that the bonding property is determined by diffusion mechanism at the Cu wire/AuAg stitch bonding interface. Finally, a brief discussion is provided on the stitch bondability of high performance Au-flashed palladium-coated copper wires on the pre-plated leadframe with different AuAg thickness.

• Periodical: Applied Mechanics and Materials (Volume 761)
• Pages: 364-368
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.761.364
• Online since: May 2015
• Authors: Sock Chien Tey*, Kok Tee Lau, Mohd Hafizul Mohamad Noor, Yon Loong Tham, Mohd Edeerozey Abd Manaf
• Keywords: Cu Diffusion, Grain Boundary, Slip Dislocations, Thermocompression, Thermosonic Bonding

References

[1] L.Y. Hung, D.S. Jiang, C.M. Huang, Y.P. Wang, Investigation of Ultrasonic Pd Coated Cu Wire Wedge Bonding on Different Surface Finish, Electronics Packaging Technology Conference, pp.705-709, Dec (2011).

DOI: 10.1109/eptc.2011.6184510

[2] C.C. Lee, L.M. Higgins, Challenges of Cu Wire Bonding and Low-k/ Cu Wafers with BOA Structures, Electronic Components and Technology Conference, pp.342-349, Jun (2010).

DOI: 10.1109/ectc.2010.5490949

[3] B. An, L. Ding, T.C. Wang, T.L. Lu, L.Q. Sun, Y.P. Wu, Improvement of the Second Bond Strength in Copper Wire Bonding on Pre-Plated Leadframe, International Conference on Electronic Packaging Technology and High Density Packaging, pp.391-394, Aug (2011).

DOI: 10.1109/icept.2011.6066860

[4] X.J. Liu, T.C. Wang, Y.Q. Cong, J.J. Wang, TEM Study on the Cu Wire Stitch Bonding Interface, Conference on Electronic Packaging Technology and High Density Packaging, pp.1-5, Aug (2011).

DOI: 10.1109/icept.2011.6067000

[5] G.G. Harman, Wire Bonding in Microelectronics, third ed., McGraw Hill, New York, (2010).

[6] B. Langenecker, Effects of ultrasound on deformation characteristics of metals, IEEE Trans. Sonics Ultrasonics, 13 (1966) 1-8.

DOI: 10.1109/t-su.1966.29367

[7] L. Levine, The Ultrasonic Wedge Bonding Mechanism: Two Theories Converge, Symposium on Microelectronics, ISHM Press, pp.128-131, (1995).

[8] K.H. Tan, F. Harun, Challenges in Copper Stitch Bond Quality on Nickel Palladium Leadframes, Electronics Manufacturing Technology Symposium, pp.1-5, Nov (2010).

[9] L.J. Loh, K.H. Loh, W.C. Ng, Further Characterization of Stitch Bond in Bare Cu Wire and Pd Coated Cu Wire on Various Leadframe Plating Scheme, International Electronic Manufacturing Technology Conference, pp.1-6, Nov (2012).

DOI: 10.1109/iemt.2012.6521781

[10] Y.H. Tian, C.Q. Wang, Y.N. Zhou, Bonding mechanism of ultrasonic wedge bonding of copper wire on Au/Ni/Cu substrate, Trans. Nonferrous Met. Soc. China, 18 (2008) 132-137.

DOI: 10.1016/s1003-6326(08)60024-2

[11] U. Tomohiro, Enhancing bondability with coated copper bonding wires, Microelectron. Reliab. 51 (2011) 88-96.

[12] X.J. Liu, T.C. Wang, Y.Q. Cong, J.J. Wang, Study on Interface of Pd-Plated Cu Wire Stitch Bonding, International Symposium on Advanced Packaging Materials, pp.213-219, Oct (2011).

DOI: 10.1109/isapm.2011.6105703
