Kinematic Modelling of a New 5-DOF (Axis) Parallel Robot Used in Brachytherapy

Abstract:

The paper presents a new medical parallel robot for brachytherapy. Brachytherapy (BT) is a relatively new and efficient medical technique for cancer treatment that enables to deliver higher doses of radiation to more-specific areas of the body, compared to the conventional form of radiation therapy that projects radiation from a machine outside the body. BT implies the implant of radioactive seeds inside the tumor, through specific needles, thus affecting only the tumor while avoiding unnecessary irradiation of the healthy tissue. Compared to the most of the brachytherapy designed only for treating the prostate, the medical robot presented in the paper is designed for hard-to-reach areas (such as the retroperitoneal area or the mediastinum). An approach regarding the robot structural synthesis, kinematics is presented followed by some simulation results obtained for a specific BT needle trajectory.

• Periodical: Applied Mechanics and Materials (Volume 762)
• Pages: 131-136
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.762.131
• Online since: May 2015
• Authors: Bogdan Gherman, Nicolae Plitea, Calin Vaida, Doina Pislă*
• Keywords: Brachytherapy, Kinematics, Modeling, Parallel Robot, Simulation

References

[1] A. Gerbaulet, R. Pötter, J-J. Mazeron, H. Meertens, E. V. Limbergen, The GEC ESTRO handbook of brachytherapy, Eur. Soc. for Ther. Rad. and Onc., Leuven, Belgium, (2002).

[2] D. Mateescu Oncology patient guide., Bennet Publishing House, Bucharest, (2010).

[3] E. Ottaviano, S. Vorotnikov, M. Ceccarelli, P. Kurenev, Design improvements and control of a hybrid walking robot, Robotics and Autonomous Systems, 59 (2011) 128-141.

DOI: 10.1016/j.robot.2010.10.002

[4] N. Plitea, et al., Structural analysis and synthesis of parallel robots for brachytherapy, New Trends in Medical and Service Robots, Springer, 16 (2014) 191-204.

DOI: 10.1007/978-3-319-01592-7_14

[5] M. Baumann, et al., Prosper: image and robot-guided prostate brachytherapy, AQUAT BOT, 32(2011) 63-65.

[6] D. Y. Song, et al., Robotic needle guide for prostate brachytherapy, Clinical testing of feasibility and performance, Brachytherapy, 10 (2011) 57-63.

DOI: 10.1016/j.brachy.2010.01.003

[7] H. Bassan, et al., A Novel Manipulator for 3D Ultrasound Guided Percutaneous Needle Insertion, Robotics and Automation Conf., (2007) 617-622.

DOI: 10.1109/robot.2007.363055

[8] Y. Yu, et al., Robot-Assisted Prostate Brachytherapy, Med Image Comput Comput Assist Interv, 9 (2006) 41-49.

[9] T. Podder, I. Buzurovic, K. Huang, Y. Yu, MIRAB: An Image-Guided Multichannel Robot for Prostate Brachytherapy, Int. J. of Radiation Oncology Biology Physics, 78 (2010) S810.

DOI: 10.1016/j.ijrobp.2010.07.1876

[10] T. Podder, G. Fichtinger, Robotic brachytherapy - overview of robotic brachytherapy approaches and synergistic applications, AAPM Annual Meeting, (2010).

DOI: 10.1118/1.3469042
