Topological and Kinematic Analysis of a 6-DOF Driving Simulator

Abstract:

Driving simulators represent a novel way to reproduce the movements of a vehicle with the purpose of testing different cars, to prevent dangerous situations, entertainment and also to train the professional drivers. More, they are used to render the effects of the interactions between the car and the road, as a consequence of the constrains imposed by the road: different folds, cavities. This work presents the topological synthesis, the kinematic analysis and the virtual modeling of driving simulator. The mechanical structure of the simulator is modeled in the Matlab/Simulink environment, generally used the advantages of numerical solutions.

• Periodical: Applied Mechanics and Materials (Volume 762)
• Pages: 119-124
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.762.119
• Online since: May 2015
• Authors: Cătălin Boantă, Ciprian Lăpusan, Dan Dumitriu, Veturia Chiroiu, Cornel Brişan*
• Keywords: Driving Simulators, Kinematic Analysis, Parallel Robots, Virtual Modeling

References

[1] R. Williams s., i., A. -R. Josh, Planar parallel 3 - prp manipulator, in Procs. of 6th of CAMR, p.4229–4235, (2006).

[2] G. Fried, K. Djouani, D. Borojeni, S. Iqbal, Determination of 3-rpr planar parallel robot assembly modes by jacobian matrix factorization, J. WSEAS Transaction on Systems, 72(2): 41–48, (2008).

[3] S. Staicu, Z. -W. Li, X. -J. Liu, J. Wang, L. -P. Wang, Matrix model in inverse dynamics of a 3-dof spatial parallel manipulator, J. U.P.B. Sci. Bull., Series D, 68 (1): 3–14, (2006).

[4] J. Kim, M. -Y. Cho, F. Park, J. M. Lee, Design of a parallel mechanism platform for simulating six degrees-of-freedom general motion including continuous 360-degree spin, CIRP Annals - Manufacturing Technology, 52(1): 347–350, (2003).

DOI: 10.1016/s0007-8506(07)60598-8

[5] J. -P. Merlet, Parallel Robots, Springer, Dordrecht, Holland, second edition, (2006).

[6] C. Lapusan, F. Fodor, C. Brisan, A. Csiszar, A. Verl, - Aspects concerning the modeling of robots with increased dexterity, ISR/Robotik 2014 - 41st International Symposium on Robotics; 6th German Conference on Robotics, Munich, (2014).

[7] J. -P. Merlet, C. -M. Gosselin, Nouvelle architecture pour un manipulateur parallèle a six dégrées de liberté e. J. Mechanism and Machine Theory, 26(1): 77–90, (1990).

DOI: 10.1016/0094-114x(91)90023-w

[8] Information on: http: /www. festo. com/rep/en_corp/assets/pdf/info_501_en. pdf.

[9] C. Brisan, C. Boanta, A. Csiszar, A. Verl – Aspects concerning kinetostatic properties of parallel robots, ISR/Robotik 2014; 41st International Symposium on Robotics, Munich, (2014).

[10] C. Brisan, A. Csiszar, Computation and analysis of the workspace of a reconfigurable parallel robotic system, Mechanism and Machine Theory, pp.1647-1668, (2011).

DOI: 10.1016/j.mechmachtheory.2011.06.014

[11] D. Zhang - Kinetostatic analysis and optimization of parallel and hybrid architectures for machine tools, Ph. D. Thesis, Laval University, Quebec, April (2000).
