One-Step Gradual Forging Process by Using Direct Heating Billet within Die

Abstract:

Direct heating billet within a die by using resistance heating method was developed to form the high strength material in one-step gradual forging process. During the forging process, the pressing speed of the upper die is controlled with the pace of the heating billet. In the proposed method, the forging die can be used as both the forming and heating of the billet. Based on this innovative forming method, experimental result shows that the billet could be heated quickly to 1000oC in about 5 seconds and the high strength material was successfully formed to the shape of bolt head in one-step gradual forging process. With the proposed mechanism, the rapidly heating and gradual deformation during the hot forging process can be successfully carried out.

• Periodical: Applied Mechanics and Materials (Volumes 764-765)
• Pages: 122-126
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.764-765.122
• Online since: May 2015
• Authors: Fang Sung Cheng*, Yu Shun Cheng
• Keywords: Direct Heating Billet within Die, One-Step Gradual Forging ́, Resistance Heating Method

References

[1] Hu, Y., Lai, Z., Zhang, Y.: 2007. The study of cup-rod combined extrusion processes of magnesium alloy (AZ61A). Journal of Materials Processing Technology 187-188, 649-652.

DOI: 10.1016/j.jmatprotec.2006.11.054

[2] Maki, S., Harada, T., Mori, K.I., Makino, H.: 2002. Application of resistance heating technique to mushy state forming of aluminium alloy. Journal of Materials Processing Technology 125-125, 477-482.

DOI: 10.1016/s0924-0136(02)00324-2

[3] Maki, S., Harada, Y., Mori, K.: 2003. Sinter-joining of different metal powder compacts using resistance heating. Journal of Material Processing Technology 143-144, 561-566.

DOI: 10.1016/s0924-0136(03)00361-3

[4] Men, A.X., Zhou, J., Xu, Z.M.: 2012. Experimental study of hot forming process by direct resistance heating. Materials Science Forum. 704-705, 252-260.

DOI: 10.4028/www.scientific.net/msf.704-705.252

[5] Mori, K., Maeno, T., Mongkolkaji, K.: 2013. Tailored die quenching of steel parts having strength distribution using bypass resistance heating in hot stamping. Journal of Material Processing Technology 213 508-514.

DOI: 10.1016/j.jmatprotec.2012.10.005

[6] Maeno, T., Mori, K., Adachi, K.: 2014. Gas forming of ultra-high strength steel hollow part using air filled into sealed tube and resistance heating. Journal of Materials Processing Technology 214, 97-105.

DOI: 10.1016/j.jmatprotec.2013.08.004

[7] Rodrigues, J.M.C., Martins, P.A.F.: 2002. Finite element modelling of the initial stages of a hot forging cycle. Finite Elements in Analysis and Design 38, 295–305.

DOI: 10.1016/s0168-874x(01)00065-8

[8] Singh, S., Maheshwari, S., Pandey, P.C.: 2004. Some investigations into the electric discharge machining of hardened tool steel using different electrode materials. Journal of Materials Processing Technology 149, 272-277.

DOI: 10.1016/j.jmatprotec.2003.11.046

[9] Shiomi, M., Ohnishi, H., Osakada, K.: 2000. A development of thixoforging using electric resistance heating. In: Proceedings of 8th International Conference on Metal Forming , Poland, pp.349-354.

[10] Yanagimoto, J., Izumi, R.: 2009. Continuous electric resistance heating—Hot forming system for high-alloy metals with poor workability. Journal of Materials Processing Technology 209, 3060-3068.

DOI: 10.1016/j.jmatprotec.2008.07.010

[11] Cheng, F.S. Cheng, Y. S.: 2014. Direct Heating Billet within Die during Hot Forging Process. Applied Mechanics and Materials 479-480, 25-29.

DOI: 10.4028/www.scientific.net/amm.479-480.25
