Depositing High-Performance Conductive Thin Films by Using Atomic Layer Deposition

Abstract:

This work characterizes the mechanical and opto-electric properties of Aluminum-doped zinc oxide (AZO) thin films deposited by atomic layer deposition (ALD), where various depositing temperature, 100, 125, 150, 175, and 200 °C are considered. The transmittance, microstructure, electric resistivity, adhesion, hardness, and Young’s modulus of the deposited thin films are tested by using spectrophotometer, X-ray diffraction, Hall effect analyzer, micro scratch, and nanoindentation, respectively. The results show that the AZO thin film deposited at 200 °C behaves the best electric properties, where its resistance, Carrier Concentration and mobility reach 4.3×10^-4 Ωcm, 2.4×10²⁰ cm^-³, and 60.4 cm²V^-1s^-1, respectively. Furthermore, microstructure of the AZO films deposited by ALD is much better than those deposited by sputtering.
