Numerical and Experimental Assessment of the Highway Arch Viaduct

Abstract:

Full–scale dynamic testing of bridge structures can provide valuable information on the service behavior and performance of structures. With the growing interest in the structural condition of highway bridges, dynamic testing can be used as a tool for assessing the integrity of bridges. From the measured dynamic response, induced by instructed passing trucks, modal parameters (natural frequencies, mode shapes and modal damping values) and system parameters (stiffness, mass and damping matrices) are obtained. These identified parameters can then be used to characterize and monitor the service of the bridge structure in the future. Analytical models of the structure can also be validated using these parameters [1,2]. The paper presents a procedure for estimating the traffic load bearing capacity of the steel arch highway viaduct Bridge Structure 205 (DC1–9, 755 m) constructed on Highway D1 in Nord Slovakia (Fig. 1) over the natural hollow basin via dynamic tests of the viaduct structures.

• Periodical: Applied Mechanics and Materials (Volume 769)
• Pages: 252-259
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.769.252
• Online since: June 2015
• Authors: Jan Bencat*, Maria Stehlikova, Milan Skarupa
• Keywords: Bridge Structures, Dynamic Loading Test, Finite Element Method (FEM), Full–Scale Bridge Testing, Highway Viaducts, Natural Frequency, Spectral Analysis

References

[1] J. Bencat et al., Static and dynamic test results of the viaduct Bridge Structure 205 on D1/DC1–9, Right Bridge, Technical Report: No. 6 – 3 – 14/SvF/12, ZU Zilina, (in Slovak), (2012).

[2] J. Bencat et al., Static and dynamic test results of the viaduct Bridge Structure 205 on D1/DC1–9, Left Bridge, Technical Report: No. 6 – 3 – 48/SvF/09, ZU Zilina, (in Slovak), (2010).

[3] L. Baca et al., Project of the viaduct Bridge Structure 205 on D1/DC1–9, Right and Left Bridge, Project documentation, Geoconsult, s. r. o., Bratislava, (in Slovak), (2009).

[4] NI LabVIEW 8. 20, Software package, National Instruments Corporation, USA, 11500 N Mopac Expy, Austin, TX 78759, (2006).

[5] IDA NEXIS 3. 2, Programs pack, Free Software Foundation, Inc., Boston, MA 02110–1301 USA, (2009).

[6] STN EN 1991–2 Eurocode 1. Basis of design and actions on structures. Part 3: Traffic loads on bridges, ÚNMS SR Bratislava, (in Slovak), (2006).

[7] Slovak Standard STN 736209, Loading Tests of Bridges, SUTN, Bratislava, (in Slovak), (1993).

[8] J. S. Bendat, A.G. Piersol, Engineering Applications of Correlation and Spectral Analysis, New York, Wiley & Sons, (1996).

[9] R. Cantieni, Dynamic behaviour of highway bridges under the passage of heavy vehicles. Report N. 220. EMPA. Duberndorf, (1992).

[10] J. Rodrigues, M. Ledesma, Dynamic Tests of a Railway Viaduct, Proceedings of the 8th International Conference on Structural Dynamics, EURODYN 2011, Leuven, Belgium, 4–6 July, (2011).

[11] C. Gentile, A. Saisi, F. Busatta, Dynamic testing and permanent monitoring of an historic iron arch bridge, EURODYN 2011, Leuven, Belgium, 4–6 July, (2011).
