Generating Guided Waves for Detection of Transverse Type-Defects in Rails

Abstract:

Detection of damage in rails can be achieved by using ultrasonic guided waves. It is practical that these waves can propagate as lengthy as possible along the rail structure. In this work, the generation of adequate guided waves is considered by performing pertinent laser irradiation of the rail head. Special laser spots were applied through out-of-phase masks collocated on both sides of the rail. Simulation of this excitation configuration was performed by means of the finite element method. It was found that the proposed method enables to trigger sufficiently high stress pulses and generate adequate pattern of waves from a lot of other modes that are likely to exist for a common rail. These waves were found to be sensitive to small localized transverse like defects in the rail system.

• Periodical: Applied Mechanics and Materials (Volume 772)
• Pages: 355-358
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.772.355
• Online since: July 2015
• Authors: Sara Teidj, Abdelaltif Khamlichi, Abdellah Driouach
• Keywords: Finite Element Method, Flaws, Guided Waves, Laser Spot Excitation, Rails

References

[1] G. Zumpano and M. Meo: International Journal of Solids and Structures 43(2006), p.1023.

[2] J.J. Marais and K.C. Mistry: Fatigue and Fracture of Engineering Materials and Structures 26(2003) p.931.

[3] J. Rose, M. Avioli, P. Mudgeand and R. Sanderson: Non Destructive Testing & Evaluation International 37(2004), p.153.

[4] S. Coccia, I. Bartoli, A. Marzani, F.L. di Scalea, S. Salamone and M. Fateh: NDT&E International 44(2011), p.93.

DOI: 10.1016/j.ndteint.2010.09.011

[5] S. Coccia, R. Phillips, I. Bartoli, S. Salamone, P. Rizzo and F.L. di Scalea: DOT/FRA/ORD-12/02, U.S. Department of Transportation, Washington, (2012).

[6] R.M. White: J. Appl. Phys. 56(1962), p.2507.

[7] H.M. Ledbetter and J.C. Moulder: J. Acoust. Soc. Amer. 34(1979), p.2527.

[8] J.D. Achenbach: Journal of Thermal Stresses 28(2005), p.713.

[9] S. Kenderian, B.B. Djordjevic and R.E. Jr. Green: Mater. Evaluat. 60(2002), p.65.

[10] F.L. di Scalea, T.P. Prendt, J.B. Spicer and B.B. Djordjevic: J. Acoust. Soc. Amer. 34(1999), p.2527.

[11] J.L. Rose, M.J. Avioli and W.J. Song: Insight 44(2002), p.353.

[12] P. Wilcox, M. Evans, B. Pavlakovic, D.N. Alleyne, K. Vine, P. Cawley and M.J.S. Lowe: Insight 45(2003), p.413.

DOI: 10.1784/insi.45.6.413.52892

[13] T. Hayashi, C. Tamayama and M. Murase: Ultrasonics 44(2006), p.17.
