Modelling of Clay Behaviour in Pile Loading Test Using One-Gravity Small-Scale Physical Model

Abstract:

The observations and tests under small scale in 1-gravity condition are intended to obtain a comparative behavior of a model and prototype of geotechnical case by imposing the scaling relations. Simulations to represent a related structure, sub-soil and failure mechanism need to be prepared prior to do observations in this modeling. To simulate pile loading test (PLT) on clay, the following models of: clay, pile, driving simulation and procedure of PLT based on ASTM D4410 were set-up. The PLT in reduced scale environment was then followed by performing normal practice of full scale PLT in original clay site. Load settlement curves obtained from both “pile loading test” in small and full scale simulations showed closely good agreement. Further observation and investigation on simulation of pile loading test in clay revealed that modeling the following: clay sub-soil resulted in new properties of clay, e_m=e_p+λLn(N) which reflects stress scaling factor, N, pile size and pile driving hammer need scaling factor n and n³ respectively whereas PLT time needs time scaling factor, t_p (n)^0.5.

• Periodical: Applied Mechanics and Materials (Volumes 773-774)
• Pages: 1535-1541
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.773-774.1535
• Online since: July 2015
• Authors: Agus Sulaeman*, Felix N.L. Ling, Martosuro Sajiharjo
• Keywords: Critical State Line Clay, Pile Loading Test, Scaling Factor, Small Scale Modeling

References

[1] Atkinson Bransby: An introduction to critical state soil mechanics McGrawhill (UK) (1978).

[2] D. M. Wood, C. Adam, and C. Taylor: Shaking table testing of geotechnical, International Journal of Physical Modelling in Geotechnics (IJPMJ) (2012).

[3] B.H. Fellenius, and A. Altae: Stress and settlement of footings in sand, Proceedings of ASCE, Geotechnical Special Publication, No. 40 College Station, Texas (1994).

[4] K. Hange, and T. J. Kvalstad: Tension pile study, Norwegian Geotechnical Institute, (1981).

[5] A. Zelikson: Geotechnical model using the hydraulic gradient method. Geotechnique, Vol 19 (1996) pp.495-508.

[6] A. Altae and B.H. Fellenius: Physical modelling in sand, Canadian Geotechnical Journal (1994).

[7] Stolle Horvart: Frustum confining vessel for testing model piles, Canadian Geotechnical Journal, 33 (1996) pp.499-504.

DOI: 10.1139/t96-071

[8] A. Sulaeman: The use of lightweight concrete pile for foundations on soft soils, phD thesis, Universiti Tun Hussein Onn Malaysia (2010).

[9] ASTM D1143-81 Standard Test Method for Piles under Static Axial Compressive Load. American Society of Testing and Material (ASTM), USA, (Reapproved 1994) pp.768-778.

[10] G. Sedran et. al.: An investigation of scaling and dimensional analysis of axially loaded piles, Canadian Geotechnical Journal (2001).
