The Field Monitoring and Finite Element Analysis of Axial Force of a Deep Foundation Pit's Reinforced Concrete Inner-Supporting

Abstract:

In this paper, a reinforce concrete inner supporting of tunnel working well is taken as the research object. Based on the result of field monitoring and numerical simulation, the change rules of axial force of inner-supporting are analyzed. By the method of field monitoring, the force condition of reinforced concrete inner-supporting can be understand. By the method of numerical simulation, the finite element model of reinforced concrete inner-supporting can be modeled by ABAQUS. The results show that, the error of measured values and design values is caused by the sensitivity of vibrating wire sensor, temperature and the shrinkage of concrete. This paper can provide a reference for similar measurement projects, whose measured values much larger than design values.

• Periodical: Applied Mechanics and Materials (Volume 775)
• Pages: 237-242
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.775.237
• Online since: July 2015
• Authors: Chong Cao, Bing Yuan, Shao Teng Huang, Jian Long Zhang, Qi Min Feng
• Keywords: ABAQUS, Field Monitoring, Finite Element Analysis, Reinforced Concrete Inner-Supporting

References

[1] Yao Shunyu, Lin Lixiang, Measurement and analysis on supporting axial force in deep foundation pit, Building Structure. 2012, 42(1): 112-114.

[2] Wang Haitao, Researches of finite element simulation and measured datum analysis of excavation of deep foundation pit, Tianjin university. (2008).

[3] Ye Wanling, Research on the axial force and deformation of reinforced concrete braces of support structures, China Civil Engineering Journal. 2000, 33(5): 83-87.

[4] Ye Zhenhua, Huang Piao, comparative analysis of the theoretical value and measured value of axial force, Geo-technical Engineering World. 2008, 12(3): 27-30.

[5] Yang Zhenwei, Concrete characteristics influencing strut axial load test, Zhejiang Hydrotechnics. 2012, 7(4): 51-55.

[6] Zhang Qihui, Strut axial forces research of reinforced concrete considering shrinking and temperature stresses, Geo-technical Engineering Technique. 2000(1): 51-54.

[7] Zhao Shiming, Finite element analysis of deep excavation considering creep behavior of concrete bracing, Building Science. 2009, 25(11): 46-50.

[8] Sun Hua'an, Application of ANSYS to prestressed reinforced concrete beam, Shanxi Architecture. 2005, 31(2): 13-15.

[9] Liu Lianglin, Wang Quanfeng, Comparison studying on finite element analysis models for reinforced concrete structures, Structural Engineers. 2007, 23(6): 15-19.

[10] Chen lei, Finite element analysis of RC structure experiment with ANSYS, Xi'an University of Technology. (2004).

[11] Huang Jifeng, Research of the nonlinear finite element analysis of reinforced concrete structures and the construction method of finite elements, China Academy of Building Research. (2001).
