The Surface Quality Detection and Electrical Discharge Mirror Machining with Non-Mixed-Powder

Abstract:

By using analytical and finite element analysis method, this paper analyzes the various factors on the impact of EDM surface roughness, puts forward a new mirror machining method of changing the order of the processing conditions and increasing the momentum of the swinging electrode in the process of EDM. Puts a measuring method for the surface quality with white light interferometer characterized by non-contact, high precision and vertical resolution in nanometer. Experiments show that in the non-mixed powder fluid, without replacing the electrodes and the processed work-piece is 45 # steel, the surface roughness of work-piece is 0.02 micro-meter, which meets the requirements for precision of the electrical discharge mirror machining.
