Forces Analysis on a Spherical Shaped Delivery Valve of Hydram Pump

Abstract:

Hydram pump has been found more than two centuries ago, and has been widely developed and operated to this day. However, constraints complaints by the people are easily damaged on its rubber of waste valve and delivery valve of the hydram pump. In addition, the reliability of the plate valve models is also awfully where its rubber of the valve is quickly worn or damaged. It has been reducing the interest of the community in utilizing hydram pumps. Moreover, there is no yet a comprehensive procedure in planning and making dimensions of hydram pump. Then, design of a spherical shaped delivery valve model on the hydram pump has been made ​​and tested. Considering that hydram pump is also called impulse pump which work due to the effects of water hammer, therefore, it need to know the forces that take place in the hydram pump. Then, from these forces can be calculated dimensions of hydram pump and its performance can be predicted. From the results of the study shows that dimensions and performance of the hydram pump is very close to the results of assessment that has been done. Finally, a procedure in planning a hydram pump has been recommended.

• Periodical: Applied Mechanics and Materials (Volume 776)
• Pages: 377-383
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.776.377
• Online since: July 2015
• Authors: Made Suarda*
• Keywords: Forces Acting on Valve, Hydram Pump, Spherical Shaped Delivery Valve, Waste Valve
