Finite Element Contact Analysis and Life Analysis of Gears in the Double-Sided Grinding Machine

Abstract:

The contact fatigue life of gears has direct influences on the working life of the double-sided grinding machine, in the actual using process, the contact fatigue life of gears cannot meet the requirements of working because of many factors. This paper uses the finite element software ANSYS, establishs the two-dimensional model of gears, and analyzes and calculates it, the research shows that: life expectancy of gears is 2.13 years, so gears should have carburizing or carbonitriding heat treatment to fit process requirements, gears can live up to 5.82 years, it can fit the technological requirements of gear life of 5 years. It is some practical value for increasing the working life of the double-sided grinding machine and improving the stability and accuracy of the whole machine.

• Periodical: Applied Mechanics and Materials (Volume 778)
• Pages: 218-221
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.778.218
• Online since: July 2015
• Authors: Nan Xing Wu, Fei Cheng, Da Hai Liao*
• Keywords: ANSYS, Contact Analysis, Life Analysis, Meshing Gears

References

[1] Li Changhe, Li Jingyao, Han Zhenlu. The technology machining of precision ultra-precision free abrasive. Qingdao university of science and technology, (2012).

[2] Zhan Chengxian. The research and design of automatic grinding machine. Xiamen university, (2008).

[3] Li Junhua. The development of double-sided CNC high speed grinding machine computer control system. Changchun university of science and technology, (2007).

[4] Mu Xuejian, Lu Weilin, Kong Yan. The development of precision double-sided grinding machine 2MM8470. Precision manufacturing and automation, 2008 (04).

[5] Wang Qiliang, Ye Xiaofen. The research of high-speed train the driving gear contact fatigue reliability of gear transmission system. The locomotive vehicle technology, (2013).

[6] Sun Zhi, Ying Cenghong. The analysis of the involute spur gear contact fatigue life base on the ANSYS Workbench. Modern machinery, (2011).

[7] Huang Zeping, Ma Jisheng, Wu Dalin. The simulation study of the gear tooth contact force. Mechanical transmission, 2007, 32(2): 26-28.

[8] Zhang Xiuhua, Li Guangxi, Wang Wan. The analysis of involute spur gear contact stress base on the ANSYS. Coal mining machinery, (2012).

[9] Yang, J.J. Trasonic Lapping of Hypoid Gear: System Design. Mechanism & Machine Theory, Jul2013, Vol. 65, pp.71-78. 8p.

DOI: 10.1016/j.mechmachtheory.2013.03.002
