Thermal Analysis of Two Wheeler Brake Disc Using ANSYS

Abstract:

This paper deals with the transient thermal analysis of brake disc of Variable Braking Force (VBF) system using computer software ANSYS. Generally, brake system is designed to apply frictional resistance to stop the vehicle. In VBF system the frictional resistance applied to the brake disc can be varied by changing the effective disc radius based on the pillion load. The rotor disc is commonly manufactured using cast iron (CI) or stainless steel (SS). In this work, these materials are taken for analysing the temperature distribution of VBF system. In addition to, an effort has been made here to suggest the best suited material for brake disc. By the way, it is evident that the rise in disc surface temperature is higher for VBF system compared with conventional system (constant effective disc radius (r) = 110mm).

• Periodical: Applied Mechanics and Materials (Volume 787)
• Pages: 301-305
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.787.301
• Online since: August 2015
• Authors: V. Ganesh*, T. Abinaya
• Keywords: ANSYS, Brake Disc, Disc Surface Temperature, Variable Braking Force

References

[1] Seung-Bok Choi, Kum-Gil Sung, Control of braking force distribution using electrorheological fluid valves, International Journal of Vehicle Design. 46 (2008) 111-27.

DOI: 10.1504/ijvd.2008.017072

[2] V. Ganesh, J. Janci Rani, Design and control of variable braking force system on a two wheeler, International Journal of vehicle Design. 60 (2012) 327-49.

DOI: 10.1504/ijvd.2012.050087

[3] Ali Belhocine, Mostefa Bouchetara, Thermomechanical modelling of dry contacts in automotive disc brake, International journal of thermal sciences. 60 (2012) 161-70.

DOI: 10.1016/j.ijthermalsci.2012.05.006

[4] B. Ghadimi, F. Kowsary and M. Khorami, Thermal analysis of locomotive wheel-mounted brake disc, Applied Thermal Engineering. 51 (2013) 948-952.

DOI: 10.1016/j.applthermaleng.2012.10.051
