Theoretical Model for the Optimal Design of Surface Texturing on Piston Compression Ring

Abstract:

A Theoretical model was developed to study the potential use of surface texturing for reducing the friction between a piston ring and cylinder liner. The model can predict the load-carrying capacity and friction force of the piston compression ring from Reynolds equation. The investigation is carried out using different dimple depths as well as different dimple diameters. Micro-dimples on the piston ring were able to generate significant hydrodynamic support. Numerical results show that surface texturing can decrease the friction force and extend the load-carrying capacity. The optimum surface texturing parameters such as dimples depth and dimples diameter were found.

• Periodical: Applied Mechanics and Materials (Volume 787)
• Pages: 327-331
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.787.327
• Online since: August 2015
• Authors: S. Prakash*, G. Nagarajan
• Keywords: Engine Friction, Hydrodynamic Lubrication, IC Engine, Piston Ring, Surface Texturing

References

[1] Gwidon W. Stachowiak., Andrew W. Batchelor, Engineering Tribology. Fourth ed. Oxford, UK, (2005).

[2] Ryk G, Etsion I, Testing piston ring with partial laser surface texturing for friction reduction, Wear. 261 (2006) 792-796.

DOI: 10.1016/j.wear.2006.01.031

[3] Holmberg K, Andersson P, Erdemir A, Global energy consumption due to friction in passenger cars, Tribol International. 47 (2012) 221–234.

DOI: 10.1016/j.triboint.2011.11.022

[4] Etsion I, Kligerman Y, Halperin G, Analytical and experimental investigation of laser-textured mechanical seal faces, Tribol Trans. 42 (1999) 511–516.

DOI: 10.1080/10402009908982248

[5] Etsion I, Halperin G, A laser surface textured hydrostatic mechanical seal, Tribol Trans. 45 (2002) 430–434.

DOI: 10.1080/10402000208982570

[6] Etsion I, Halperin G, Brizmer V, Kligerman Y, Experimental investigation of laser surface textured parallel thrust bearings, Tribol Lett. 17 (2004) 295–300.

DOI: 10.1023/b:tril.0000032467.88800.59

[7] A. Shinkarenko, Y. Kligerman, I. Etsion, The effect of surface texturing in soft elasto-hydrodynamic lubrication, Tribology International. 42 (2009) 284– 292.

DOI: 10.1016/j.triboint.2008.06.008

[8] I. Etsion, E. Sher, Improving fuel efficiency with laser surface textured piston rings, Tribology International. 42 (2008) 542-547.

DOI: 10.1016/j.triboint.2008.02.015

[9] Yuankai Zhou, Hua Zhu, Wei Tang, Development of the theoretical model for the optimal design of surface texturing on cylinder liner, Tribology International. 52 (2012) 1–6.

DOI: 10.1016/j.triboint.2011.12.017

[10] Beomkeun Kim, Young Hun Chae, Heung Soap Choi, Effects of surface texturing on the frictional behavior of cast iron surfaces, Tribology International. 70 (2014) 128–135.

DOI: 10.1016/j.triboint.2013.10.006

[11] Y. Kligerman, I. Etsion, A. Shinkarenko, Improving tribological performance of piston rings by partial surface texturing, Journal of Tribology. 127 (2005) 632-638.

DOI: 10.1115/1.1866171

[12] B. Podgornik, M. Sedlacek, Performance, characterization and design of textured surfaces, Journal of Tribology. 134 (2012) 041701-7.

DOI: 10.1115/1.4007108

[13] Hugo M. Checo, Roberto F. Ausas, Mohammed Jai, Jean-Paul Cadalen, Franck choukroun, Gustavo C. Buscaglia, Moving textures: Simulation of a ring sliding on a textured liner, Tribology International. 72 (2014) 131–142.

DOI: 10.1016/j.triboint.2013.12.013
