The Effect of Heat Temperature on the Structure of Plasma Coating of the Ni-Cr-Si-B System

Abstract:

The powder of the Ni-Cr-Si-B system was applied on tubes of low carbon steel (0.2 % C) with the help of air-plasma spraying. The effect of heating temperature on the microstructure of obtained coatings was analyzed in this paper. The coatings were heated up to 500, 600, 700, 800, 900, 1000, and 1100 °C and cooled in the air. It was shown by the method of optical and scanning electron microscopy (SEM) and the X-ray diffraction analysis (XRD) that the same phases (γ-Ni, Ni₃B, Ni₃Si and Cr₂B) were present in the coatings before and after heating. Chromium carbide Cr₇C₃ was observed in the coating structure after heating to above 1000 °C. Coatings which were heated to 1000 °C consisted of grains of the solid nickel base solution, micro volumes of the Ni+Ni₃Si eutectic with inclusions of Ni₃B and particles of Cr₇C₃. The coatings which were crystallized from a liquid state (heated up to 1100 °C) consisted of large areas of the solid nickel base solution and particles of chromium carbide Cr₇C₃. The space between nickel areas is filled by the Ni₃Si+Ni₃B eutectic.

• Periodical: Applied Mechanics and Materials (Volume 788)
• Pages: 252-258
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.788.252
• Online since: August 2015
• Authors: Elena Kornienko*, Aelita Nikulina, Ekaterina Drobyaz, Natalya V. Plotnikova, Elizaveta Lapushkina, Viktor Kuzmin
• Keywords: Air-Plasma Spraying, Heating, Self-Fluxing Powder

References

[1] J.H. Chang, T.H. Liu, J.M. Chou, R.I. Hsieh, J.L. Lee, Microstructural and microhardness characteristics of induction melted nickel-based alloys, Materials chemistry and Physics 120 (2010) 702-708.

DOI: 10.1016/j.matchemphys.2009.12.020

[2] I. Hemmati, V. Ocelik, J. Th.M. De Hosson, Effects of the alloy composition on phase constitution and properties of laser deposited Ni-Cr-B-Si coatings, Physics Procedia 41 (2013) 302-311.

DOI: 10.1016/j.phpro.2013.03.082

[3] I. Hemmati, V. Ocelik, K. Csach, J. Th.M. De Hosson, Microstructure and phase formation in a rapidly solidified laser-deposited Ni-Cr-B-Si-C hardfacing alloy, Metallurgical and materials transactions A 45F (2014) 878-892.

DOI: 10.1007/s11661-013-2004-4

[4] C. Navas, R. Colaco, J. de Damborenea, R. Vilar, Abrasive wear behavior of laser clad and flame sprayed-melted NiCrBSi coatings, Surface & Coatings Technology 200 (2006) 6854-6862.

DOI: 10.1016/j.surfcoat.2005.10.032

[5] Hui-Feng Xuan, Qin-Ying Wang, Shu-lin Bai, Zong-De Liu, Hua-Gang Sun, Peng-Cheng Yan, A study on microstructure and flame erosion mechanism of graded Ni-Cr-B-Si coating prepared by laser cladding, Surface & Coatings Technology 244 (2014) 203-209.

DOI: 10.1016/j.surfcoat.2014.02.021

[6] I. Hemmati, V. Ocelik, J. Th.M. De Hosson, Advances in laser surface engineering: tackling the cracking problem in laser-deposited Ni-Cr-B-Si-C alloys, JOM 65(6) (2013) 741-748.

DOI: 10.1007/s11837-013-0594-3

[7] H. Saricimen, A. Quddus, A. UI-Hamid, Hot corrosion behavior of plasma and HVOF sprayed Co- and Ni-based coatings at 900 °C, Protection of metals and physical chemistry of surfaces 50(3) (2014) 391-399.

DOI: 10.1134/s2070205114030162

[8] N. Serres, F. Hlawka, S. Costil, C. Langlade, F. Machi, an investigation of the mechanical properties and wear resistance of NiCrBSi coatings carried out by in situ laser remelting, Wear 270 (2011) 640-649.

DOI: 10.1016/j.wear.2011.01.025

[9] E. Drobyaz, T. Zimoglyadova, V. Gromov, Electron-Beam Surfacing Wear-Resistant Coatings, Reinforced Refractory Metal's Borides, Applied Mechanics and Materials 698 (2015) 419-423.

DOI: 10.4028/www.scientific.net/amm.698.419

[10] Z. Zeng, S. Kuroda, H. Era, Comparison of oxidation behavior of Ni-20Cr alloy and Ni-base self-fluxing alloy during air plasma spraying, Surface & Coatings Technology 204 (2009) 69-77.

DOI: 10.1016/j.surfcoat.2009.06.036

[11] C. Guoqing, F. Xuesong, W. Yanhui, Z. Wenlong, Microstructure and wear properties of nickel-based surfacing deposited by plasma transferred arc welding, Surface & Coatings Technology 228 (2013) 276-282.

DOI: 10.1016/j.surfcoat.2012.05.125

[12] E. Kornienko, E. Lapushkina, V. Kuzmin, S. Vaschenko, I. Gulyaev, E. Kartaev, D. Sergachev, N. Kashapov, S. Sharifullin, I. Fayrushin, Air plasma sprayed coatings of self-fluxing powder materials, Journal of Physics: Conference Series 567 (2014).

DOI: 10.1088/1742-6596/567/1/012010

[13] E. Kornienko, A. Smirnov, V. Kuzmin, Structure and Properties of Self-fluxing Coating, Obtained by Air-plasma Spraying, Applied Mechanics and Materials 698 (2015) 405-410. doi: 10. 4028/www. scientific. net/AMM. 698. 405.

DOI: 10.4028/www.scientific.net/amm.698.405

[14] Yu.S. Chesov, E.A. Zverev, V.V. Ivancivsky, V.U. Skeeba, N.V. Plotnikova, D.V. Lobanov Structure of wear resistant plasma coatings after high-energy treatment using high-frequency currents, Obrabotka metallov (tekhnologiya, oborudovanie, instrumenty) (in Russian) 4 (2014).

[15] A.F. Puzryakov, The Theory of Plasma Spraying, MGTU im. N.E. Baumana, Moscow, (2003).

[16] L.I. Tushinski, A.V. Plohov, A.O. Tokarev, V.I. Sindeev, Methods of Materials Research: Structure, Properties and Processes of Applying of Inorganic Coatings, Mir, Moscow, (2004).

[17] P. Zhang, H. Yan, P. Xu, Q. Lu, C. Li, Z. Yu, Influence of different annealing temperatures and cooling rates on amorphous and crystalline composite coating, Surface & Coatings Technology 206 (2012) 4981-4987.

DOI: 10.1016/j.surfcoat.2012.05.142

[18] E. Kornienko, E. Lapushkina, D. Sergachev, Plasma spraying of wear-resistant coatings, In Proceedings of 20th International Conference for Students and Young Scientists Modern Technique and Technologies, 2 (2014) 51-52.

[19] T. Tokunaga, K. Nishio, M. Hasebe, Thermodynamic study of phase equilibria in the Ni-Si-B system, Journal of phase equilibria 22(3) (2001) 291-299.

DOI: 10.1361/105497101770338798

[20] A.G. Alexeev, G.A. Bovkun, A.S. Bolgar, Properties, obtaining and use of refractory combination, Metallurgy, Moscow, (1986).
