Research of Non-Sinusoidal Voltage in Frequency Converter of Medium Power Operation

Abstract:

The article presents the comparative analysis of influence frequency regulated electric drive and current electric drive to harmonic structure of voltage of power grid. There was obtained the dependence of total harmonic distortion (THD) of curve on loading power for 2 types of valve converters. The effectiveness is shown in use of filter compensating device, connected at low side of converting transformer. There were defined the ranges of filter adjusting for improving THD of voltage curve. The described solutions are performed by the structural modeling method of Simulink packet in Matlab environment.

• Periodical: Applied Mechanics and Materials (Volume 792)
• Pages: 8-14
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.792.8
• Online since: September 2015
• Authors: Gennady Petrovich Kornilov*, Ildar Ravil’evich Abdulveleev, Timur Rifkatovich Khramshin
• Keywords: Filter Compensating Device, Frequency Converter, Frequency Regulated Electric Drive, Highest Harmonics, Thyristor Converter

References

[1] Khramshin T.R. Kornilov G.P., Nikolaev A.A. et al. Study of the impact on the supply network of active high power rectifiers [Issledovanie vozdeystviya na pitayuschuyu set aktivnyih vyipryamiteley bolshoy moschnosti], Vestnik Ivanovskogo gosudarstvennogo energeticheskogo universiteta [Bulletin of Ivanovo State Power University], 2013, no. 1, pp.80-83.

[2] Khramshin T.R. Ways to improve the stability of electric drives of continuous production with voltage drops [Sposobyi povyisheniya ustoychivosti elektroprivodov nepreryivnyih proizvodstv pri provalah napryazheniya] / T.R. Khramshin, G.P. Kornilov, D.S. Krubcov et al. / Vestnik Yuzhno-Uralskogo gosudarstvennogo universiteta Seriya Energetika [Bulletin of the South Ural State University. Series: Power Engineering], 2014, no 2, pp.80-87.

[3] Fedorov A.A. and Kornilov G.P. The use of compensating devices in power systems with powerful non-linear loads [O primenenii kompensiruyuschih ustroystv v sistemah elektrosnabzheniya s moschnyimi nelineynyimi nagruzkami] / Electrichestvo [Electricity], 1980, no. 7, pp.64-67.

[4] Fedorov A.A. and Kornilov G.P. Improving the technical and economic indicators of valve DC converters [Povyishenie tehniko-ekonomicheskih pokazateley ventilnyih preobrazovateley postoyannogo toka] / Promyshlennaya energetika [Industrial power], 1977, no. 11, pp.46-48.

[5] Khramshin T.R., Abdulveleev I.R., Kornilov G.P. Implementation of EMC powerful electrical systems [Obespechenie elektromagnitnoy sovmestimosti moschnyih elektrotehnicheskih kompleksov], Vestnik Yuzhno-Uralskogo gosudarstvennogo universiteta Seriya Energetika [Bulletin of the South Ural State University. Series: Power Engineering], 2015, no. 1, pp.82-93.

[6] Fedorov A.A. and Kornilov G.P. Quality and effective use of electric power [O kachestve elektroenergii i ee effektivnom ispolzovanii] / Promyshlennaya energetika [Industrial power], 1983, no. 9, pp.30-32. (in Russ. ).

[7] Kornilov G.P. and Sorokin A.I. Power quality in power supply systems with powerful rectifier converter [Kachestvo elektroenergii v sistemah elektrosnabzheniya s moschnyimi ventilnyimi preobrazovatelyami] / Promyshlennaya energetika [Industrial power], 1978, no. 11, pp.27-29.

[8] Khramshin T.R., Krubtsov D.S., Kornilov G.P. Evaluation methods of pulse width modulation voltage rectifiers active mills, Russian Internet Journal of Industrial Engineering, 2013, no. 2, pp.48-52. (in Russ. ).

[9] Chang G.W. An analytical approach for characterizing harmonic and interharmonic currents generated by VSI-fed adjustable speed drives/ Chang G.W., Chen Shin-Kuan / IEEE Transactions On Power Delivery. – October, 2005. – Vol. 20, No. 4. – P. 2585 – 2593.

DOI: 10.1109/tpwrd.2005.855487

[10] Rodriguez J. Multilevel voltage-source-converter topologies for industrial medium-voltage drives / J. Rodriguez, S. Bernet, B. Wu, J. Pontt, S. Kouro / IEEE Trans. Ind. Electron. – 2007. – Vol. 54. – № 6. – P. 2930-2945.

DOI: 10.1109/tie.2007.907044

[11] Khramshin T.R., Krubtsov D.S., Kornilov G.P. Evaluation methods of pulse width modulation voltage rectifiers active mills, Russian Internet Journal of Industrial Engineering, 2013, no. 2, pp.48-52. (in Russ. ).

[12] Almula A. Simulation and implementation of twolevel and three-level inverters by matlab and RT-LAB / A. Almula, G.M. Gebreel. – The Ohio State University, 2011. – 136 p.

[13] Khramshin T.R., Abdulveleev I.R., Kornilov G. P Mathematical Model of the Power Circuit of STATCOM of Large Capacity [Matematicheskaya model silovoy shemyi moschnogo STATKOMa], Russian Internet Journal of Electrical Engineering, 2015, vol. 2, no. 1, pp.38-46.

DOI: 10.24892/rijee/20150106
