Development of a Tool Changer for a Reconfigurable Machine Tool

Abstract:

Automated tool changing of CNC machines reduces the cycle time of operations as most processes require a number of different tools to complete a task. The machine can be pre-loaded with the required tools and programmed to automatically retrieve the tools as required. CNC machines will often run unattended or work too quickly for manual intervention, so it is important that safety features and checks are built in to prevent damage. The purpose of this research project was to modify a tool changing system for a reconfigurable machine tool (RMT), which was previously developed in the Department of Mechatronics. The RMT is capable of performing milling, drilling and electric discharge machining (EDM). In this research, the automated tool changer (ATC) was developed and successfully integrated into the RMT, and interfaced with the machine controller. The redesigned ATC is able to provide fast, reliable and safe tool changing for a variety of tools.

• Periodical: Applied Mechanics and Materials (Volume 798)
• Pages: 324-328
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.798.324
• Online since: October 2015
• Authors: Ian McLaren*, I. Gorlach
• Keywords: CNC Machine, Reconfigurable Machines, Tool Changer

References

[1] Y. Koren, A.G. Ulsoy, Reconfigurable Manufacturing Systems, Engineering Research Center for Reconfigurable Machining Systems (ERC/RMS) , The University of Michigan, Ann Arbor, (1997).

[2] M.G. Mehrabi, A.G. Ulsoy, 1997-a and b, State-of-the-Art in Reconfigurable Manufacturing Systems, Report #2, Vol. I and II, Engineering Research Centre for Reconfigurable Machining Systems (ERC/RMS), University of Michigan, Ann Arbor, (1997).

[3] M.G. Mehrabi, A.G. Ulsoy, Y. Koren, Reconfigurable Manufacturing Systems: Key Feature Manufacturing, Journal of Intelligent Manufacturing, 11/4: 403-419, (2000).

DOI: 10.1023/a:1008930403506

[4] M.G. Mehrabi, A.G. Ulsoy, Y. Koren, P. Heytler, Trends and Perspectives in Flexible and Reconfigurable, (2002).

[5] M. Simpson, I. A Gorlach, Development of a Reconfigurable Machine Tool, International Conference on Competitive Manufacturing, COMA'10, February 2010, Stellenbosch, South Africa.

[6] W. Estment, I.A. Gorlach, G.J. Wiens, Design of sub-systems of a reconfigurable machine tool, CAD/CAM Robotics and Factories of the Futures Conference, July 2010, Pretoria, South Africa.

[7] T.V. Light, I.A. Gorlach, G.J. Wiens, Dynamic Simulation of a Special Purpose CNC Machine, International Conference on Systems, Corfu Island, Greece, (2011).

[8] M. Simpson, T.V. Light, I.A. Gorlach, B. Roberts, Development of A Prototype of a Special Purpose Machine, Proceedings of The 20th IASTED International Conference on Applied Simulation and Modelling, July 2012, Italy, Napoli.

DOI: 10.2316/p.2012.776-012

[9] T. Ferreira, I.A. Gorlach, Development of a Controller for a Reconfigurable Manufacturing Cell, Recent Advances in Telecommunications & Circuits: 2nd International Conference on Circuits, Systems, Communications, Computers and Applications (CSCCA '13), June 2013, Dubrovnik, Croatia.
