A FEM Frontal Impact Study of Square-Section Tubes with Different Structural Solutions for Vehicle Safety

Abstract:

The present paper presents a study of square-section tubes conditioned to a FE dynamic frontal impact analysis, considering a 10.0 m/s initial velocity against an infinitely rigid plane. A 50.0 kg punctual mass is positioned on center of the cross-sections, on the farthest side from the rigid plane and the deceleration pulse is measured along the simulations. After validating the numerical model with analytical solutions, the results are compared for four geometries with little structural differences in order to access the role of each difference on the geometry under crash situations. The results show that adding many triggers to the geometry may not be the best performance solution for crash boxes, since the geometry with few triggers achieved better values of deceleration peak than the others. In addition, the presence of holes showed to be an instability cause to the system. The structural solutions presented could be of great value for future vehicle crash box developments.

• Periodical: Applied Mechanics and Materials (Volume 798)
• Pages: 36-40
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.798.36
• Online since: October 2015
• Authors: Ciro Faria Maia*, Guilherme Silame Maranhão Lima, Felipe Grossi L. Amorim, Evandro Queiroz Nunes Vera, Alexander Matioli Pasqual
• Keywords: Crash, Crash Box, Dynamic Analysis, FEM, Structure

References

[1] National Department of Transport and Infrastructure, Brazil, DNIT (2011), http: /dnit. gov. br.

[2] Du Bois, Paul, Clifford C. Chou, Bahig B. Fileta, Tawfik B. Khalil, Albert I. King, Hikmat F. Mahmood, Harold J. Mertz, Jac Wismans, Priya Prasad, and Jamel E. Belwafa. Vehicle crashworthiness and occupant protection. (2004).

[3] Hou, S., Li, Q., Long, S., Yang, X., & Li, W. (2007). Design optimization of regular hexagonal thin-walled columns with crashworthiness criteria. Finite Elements in Analysis and Design, 43(6), 555-565.

DOI: 10.1016/j.finel.2006.12.008

[4] Nia, A. A., & Hamedani, J. H. (2010). Comparative analysis of energy absorption and deformations of thin walled tubes with various section geometries. Thin-Walled Structures, 48(12), 946-954.

DOI: 10.1016/j.tws.2010.07.003

[5] Zhang, X., Wen, Z., & Zhang, H. (2014). Axial crushing and optimal design of square tubes with graded thickness. Thin-Walled Structures, 84, 263-274.

DOI: 10.1016/j.tws.2014.07.004

[6] An, X., Gao, Y., Fang, J., Sun, G., & Li, Q. (2015). Crashworthiness design for foam-filled thin-walled structures with functionally lateral graded thickness sheets. Thin-Walled Structures, 91, 63-71.

DOI: 10.1016/j.tws.2015.01.011

[7] Abramowicz W, Jones N. Dynamic axial crushing of square tubes. International Journal of Impact Engineering 1984; 2(2): 179-208.

DOI: 10.1016/0734-743x(84)90005-8

[8] Abramowicz W, Jones N. Dynamic progressive buckling of circular and square tubes. International Journal of Impact Engineering 1986; 4(4): 243-70.

DOI: 10.1016/0734-743x(86)90017-5

[9] Autosteel | Resources on Steel's Role in Automotive Design & Engineering, http: /autosteel. org.

[10] John, O. H. (1998). LS-DYNA theoretical manual. Livermore Software Technology Corporation, California.
