Combined Compliance Method of the Variable Cross Section Flexure Hinge and its Verification

Abstract:

Flexure hinge is the most basic compliant structure, the compliance is one of the important performance parameter. The structure characteristics is analysed and the new method used for calculating the compliance is performed in this paper. Based on the structure characteristics analysis of the right circle, corner filleted and elliptical flexure hinge (symmetric and non-symmetric), half flexure hinges are analysed and the compliance formulas are given by selecting the reasonable integral variable. The combined compliance formulas of 12 kinds flexure hinge (simple, hybrid (symmetric,non-symmetric)) are obtained by half different types of flexure hinge being combined. The right circular flexure hinge, right circular elliptical hybrid flexure hinge and non-symmetric elliptical flexure hinge are selected and their compliance are calculated with the formulas in this paper and in literatures, which results indiceted the validity and correctness of the combined compliance method.

• Periodical: Applied Mechanics and Materials (Volume 798)
• Pages: 85-91
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.798.85
• Online since: October 2015
• Authors: Qing Ling Liu*, Xing Xin Wang
• Keywords: Combined Compliance, Structure Characteristics, Variable Cross Section Flexure Hinge, Verification

References

[1] Li Yuhe, Li Qingxiang, Chen Luyun. Study on design method of one-axis flexure hinge[J]. JT sing hua Univ (Sci & Tech) . Vol, 42(2002), p.172.

[2] Yang Chunhui. Calculation and Analysis for Corner-filleted Flexure Spherical Hinge[J]. MACHINE TOOL & HYDRAULICS. Vol, 41(2013), p.55.

[3] Zhao Lei, Gong Yan, Hua Yangyang. Compliance Matrix Analysis of Corner filleted Flexure Hinge[J]. China Mechanical Engineering. Vol, 24(2013), p.2462.

[4] PAROS J M, WEISBORD L. How to design flexure hinges[J]. Machine Design. Vol, 37(1965), p.151.

[5] CHEN Gui-min, JIA Jian-yuan, GOU Yan-jie. Study on a Hybrid Flexure Hinge[J]. Chinese Journal of Scientific Instrument. Vol, 25(2004), p.1.

[6] CHEN Gui-min, JIA Jian-yuan, LIU Xiao-yuan, GOU Yan-jie. On Right-circular Elliptical Flexure Hinge[J]. Machine Design And Research. Vol, 21(2005), p.37.

DOI: 10.1109/coase.2005.1506777

[7] ZHANG Zhi-jie, YUAN Yi-bao, YU Wen. Design Calculation and Analysis of Half elliptical Flexure Hinge[J]. Machine Design And Research. Vol, 2(2007), p.50.

[8] Liu Qingling, Weng Haishan, Qiu Lifang. Compliances Calculation and Behavior Analysis of the Half Right Circular Elliptical Hybrid Flexure Hinge[J]. Engineering Mechanics. Vol, 27( 2010), p.52.

[9] Nicolae lobontiu. Compliant mechanisms: design of the flexure hinges. 2003 by CRC Press LLC. p.447.
