The Detection and Analysis of Straightness Errors on Pillar and Guide Rail of Alien Stone Turning-Milling Compound Machining Center

Abstract:

The alien stone turning-milling compound machining center is a new generation gap multifunctional compound machining center. It is used to process rotating part of alien stone products and three-dimensional sculpture products. The pillar and guiding rail are the key parts of the machining center. The straightness error of the pillar and guide rail seriously impacts the linear motion precision of beam parts. Comparison the straightness of guiding rail with pillar or without pillar, it shows that the results meet the standard of GB/T16462-1996. So it ensures the accuracy of the linear motion precision of beam parts. It lays a solid foundation for achieving the design function and machining precision.

• Periodical: Applied Mechanics and Materials (Volumes 80-81)
• Pages: 480-484
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.80-81.480
• Online since: July 2011
• Authors: Ke Zhang, Zheng Xing Cui, De Hong Zhao, Liang Wu Rao, Yu Hou Wu
• Keywords: Alien Stone, Machining Center, Straightness, Two-Endpoint Method

References

[1] WANG Qixia, LI Wei. Prototype and Precision Analysis of Straightness Testing Apparatus [J]. Machine Tool&Hydraulics. 37(2009) pp.119-121.

[2] Feng Qibo, Zhang Bin, Kuang Cuifang. A straightness measurement system using a single -mode fiber-coup led laser module[ J ]. Optics & Laser Technology. 36 (2004) pp.279-283.

DOI: 10.1016/j.optlastec.2003.09.016

[3] Ding Ye, Zhu Limin, Ding Han. A unified approach for circularity and spatial straightness evaluation using semi-definite programming[J]. International Journal of Machine Tools &Manufacture. 47 (2007) pp.1646-1650.

DOI: 10.1016/j.ijmachtools.2006.12.001

[4] HU Changde, LU Jiahai, XING Qi, GAO Juan. Length based on laser interference measuring Straightness Error[J]. Optical instruments. 30 (2008) pp.10-15.

[5] Li Yilin. Straightness error of the computer visual assessment[J]. Machine Tool&Hydraulics. 37 (2009) pp.124-126.

[6] Hu Tianxi, Yan Zhen, Zemg Tao. Several Straightness error measurement method[J]. Mechanical engineering and automation. 2 (2008) pp.186-187.

[7] Rao Liusheng, Hou Liang, Pan Yongjun. Machine based on the relative density of the column structure of the Optimal Dynamic Topology[J]. The mechanical design and research. 26 (2010) pp.87-92.

[8] Han Lijuan, Zhang Licheng, Wang Youyong. Measuring Straightness Error for Machine Tool Slide Guide and Data Processing[J]. Coal machinery. 28 (2007) pp.83-85.

[9] Xu Ronghua. Research on alignment test and error evaluation for guideway[J]. Journal of ShangHai college of electricity&machinery technology. 7 (2004) pp.103-104.
