Design of State Monitoring System of Internal Combustion Engine Based on Serial Bus

Abstract:

This paper introduces a type of control and test system for internal combustion engine based on Serial bus and virtual instrument technique. It consists of host and intelligent node, with parameter signals communication through RS485 serial bus to form a distributed high-precision status parameters controlling testing system. The host computer implements the user interaction, data storage, status monitoring, power measurement and computation as well as management. The client unit reads the commands of host, controls the rotation speed of engine and excitation current, detects all the parameters of system and transmits the data. The hardware and software structure of the distributed testing system (client) with ATmega128 micro single chip computer and communication module are implemented. And the application software was developed with graphical virtual instrument language LabVIEW. The solution may have some reference value to the design of other internal combustion monitoring system with other control bus and the development of general single chip microcomputer and industrial field monitoring and controlling system.

• Periodical: Applied Mechanics and Materials (Volumes 80-81)
• Pages: 591-595
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.80-81.591
• Online since: July 2011
• Authors: Ke Feng, Xiao Ming Meng, Xiao Long Wang, Guo Liang Lu
• Keywords: Construction Machinery, Diesel Engine, Host Computer, Intelligent Node, RS485 Bus, Virtual Instrumentation

References

[1] R. Yunpeng, H. Tianyou, Y. Ping, and L. Xin. Approach to Diesel Engine Fault Diagnosis Based on Crankshaft Angular Acceleration Measurement and its Realization. Proceedings of the IEEE International Conference on Mechatronics & Automation, vol. 3, pp.1451-1454, July (2005).

DOI: 10.1109/icma.2005.1626769

[2] Yi Wang et al. The intelligent fault diagnosis of construction machinery based on multi-agent. 2011, Applied Mechanics and Materials, 48-49, 1383.

DOI: 10.4028/www.scientific.net/amm.48-49.1383

[3] Pan Wei, Wang Hangong. On-line state monitoring of hydraulic system for construction machinery. Maintenance forum (in Chinese), pp.32-34, July (2004).

[4] Lino Guzzella and Christopher H. Onder. 2004. Introduction to Modeling and Control of Internal Combustion Engine Systems. Berlin, Germany: Springer.

[5] Lloyd's Register of Shipping. 1984. Part 6, Control Engineering Systems. Rules and Regulations for the Classification of Ships. London.

[6] http: /www. flightsystems. com/InstallPDF/Model550. pdf.

[7] Kim chong-fou et al. Micro single chip computer program design and practice of AVR ATmega128. Beijing; press of Beijing University of Aeronautics, (2007).

[8] http: /www. datasheetarchive. com/pt100 measurement-datasheet. html.
