The Vertical Forces Introduced by Wind on the Active Pantograph from Bodywork of Locomotive LE 060 EA of 5100 kW

Abstract:

Gusts of wind with high speed can adversely affect the operation of the electric railway vehicles. These vehicles are able to move and to obtain a high performance, as long as the power supply is ensured. The variation of the vertical forces for maintaining contact between pantograph and catenary may cause interruption of the power supply of the electric railway traction vehicles. The placement of the capture equipment on the vehicle body determines appearance of aerodynamic forces acting on it. To see which are the vertical forces introduced by wind on active capture equipment, used at locomotives LE 060 EA of 5100 kW, we considered the EP3 type of pantograph as model. This was modelled at scale 1:1 taking into account the placement on the body of the locomotive. For the simulation of wind we considered three point values of its speed (10 m/s, 20 m/s, 30 m/s) and angle of eight values that are within the range of 0 deg – 180 deg. With the results of the simulation we have done a comparative analysis on the additional vertical forces introduced by wind for the cases analyzed.

• Periodical: Applied Mechanics and Materials (Volumes 809-810)
• Pages: 1115-1120
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.809-810.1115
• Online since: November 2015
• Authors: Sorin Arsene*
• Keywords: Flow Simulation, Pantograph, Vertical Force, Wind Gusts

References

[1] R. Gregoire, A. Collina, F. Resta, D. Rocchi, Some considerations on the aerodynamics of high speed pantograph: cfd and wind tunnel tests, BBAA VI International Colloquium on: Bluff Bodies Aerodynamics & Applications, Milano, (2008).

[2] J. Pombo, J. Ambrósio, M. Pereira, F. Rauter, A. Collina, A. Facchinetti, Influence of the aerodynamic forces on the pantograph–catenary system for high-speed trains, Vehicle System Dynamics. 47 (2009) 1327-1347.

DOI: 10.1080/00423110802613402

[3] I. Sebeșan, S. Arsene, C. Stoica, Experimental study on determination of aerodynamic resistance to progress for electric locomotive LE 060 EA1 of 5100 kW, U.P.B. Sci. Bull. Series D 75 (2013) 85-96.

[4] I. Sebeșan, S. Arsene, C. Stoica, Experimental analysis for aerodynamic drag of the electric locomotives, INCAS BULLETIN. 5 (2013) 99-115.

[5] S. Arsene, The Influence of wind on the active pantograph located on the body of locomotive LE 060 EA of 5100 kW (in Romanian), Symposium Railway Rolling Stock, Ed. MatrixRom, Bucharest, 2014, pp.209-219.

DOI: 10.4028/www.scientific.net/amm.809-810.1115

[6] S. Arsene, Analysis regarding the aerodynamic resistances on boxes electric locomotives, The International Conference on INnovation and Collaboration in Engineering Research INCER, Bucharest, 2013, pp.157-160.

[7] I. Sebeşan, S. Arsene, Study on aerodynamic resistance to electric rail vehicles generated by the power supply, INCAS BULLETIN. 6 (2014) 151-158.
