Optimization Design of a 500 kN Workover Rig Mast after Computer Simulated Overload Test

Abstract:

The 500 kN mast, which is part of a workover rig used for interventions and overhauling works for oil and gas wells, is a spatial multiple indeterminate structure made of many bars, with rigid nodes. The aim of this paper is to determine, through computer simulation of overload test, the state of stress and displacements for the existing construction and to find an improved solution. The overload test is experimentally realized on specialized stands and involves the mast’s loading with the maximum hook load multiplied by a safety factor of 1.4 and, in addition, with the dead weight, the hoisting system weight, and with the corresponding forces due to the draw works drum socket and the blind end. Since this is a prototype construction made of structural steel rectangular pipes and profiles as L, I, U-shaped cross section, such an analysis is necessary to ensure the mast’s and rig’s safety during functioning.

• Periodical: Applied Mechanics and Materials (Volumes 809-810)
• Pages: 932-937
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.809-810.932
• Online since: November 2015
• Authors: Lavinia Silvia Stanciu*, Ioan Popa
• Keywords: Displacements, Drilling Mast, Overload Test, Stress, Workover Rig

References

[1] I. Popa, L. S. Stanciu, Stress and displacements analysis for drilling mast elements made of rectangular pipe: the overload test case, Key Engineering Materials. 601 (2014) 120-123.

DOI: 10.4028/www.scientific.net/kem.601.120

[2] Al. Pupăzescu, I. Popa, L. S. Stanciu, The Evaluation of the Stress and Strain Condition for the Mast MU 320 Made out of U and I Profile Beams (in Romanian), Petroleum-Gas University of Ploieşti Bulletin, Technical Series. LX, 3A (2008) 223-228.

[3] L. S. Stanciu, I. Popa, Stress and Displacements Analysis for Drilling Mast Elements Made of Rectangular Pipe under the Action of the Wind as a Hurricane, Key Engineering Materials. 601 (2014) 116-119.

DOI: 10.4028/www.scientific.net/kem.601.116

[4] Ş. Vasilescu, An Approximate Method Used in the Calculation of the Critical Load for Beams with Variable Cross Sectional Area (in Romanian), Petroleum –Gas University Bulletin, Technical Series. 3, LXIII (2012) 23-29.

[5] I. Lambrescu, I. Pană, Theoretical and experimental fatigue analysis for the mast MU450 top drive drilling mast with impact on the reliability, in the proceedings of Balkantrib'14, 8th international Conference on Tribology, Sinaia, Romania, 2014, pp.656-664.

[6] I. Lambrescu, N. Posea, Predictive analysis of the dynamic behaviour of structures, Buletinul Institutului Politehnic din Iaşi. Tom LII(LVI), Fasc. 5B (2006) 701-705.

[7] I. Pană, Pasco Babe, Drilling Rigs Modelling Using AVEVA PDMS Software (in Romanian), Petroleum – Gas University of Ploieşti Bulletin, Technical series. LXIII, 3 (2011) 13-19.

[8] ANSYS Release 10. 0 Software.

[9] SR EN 10056-1, Specifications for structural steel equal and unequal angles. Part 1: Dimensions (in Romanian).

[10] EN 1993-1, Eurocod 3: Design of steel structures (in Romanian).

[11] API 4F, Specifications for Drilling and Well Servicing Structures, Third Edition, API energy, Washington, (2008).

[12] STAS 1909-89, Derricks and masts for drilling and intervention. Design specifications (in Romanian).

[13] Al. Anghel, Strength of materials, Part 2 (in Romanian), Petroleum – Gas University of Ploieşti Publishing House, Ploieşti, 2005, pp.46-65.
