Controlling the Additives in Lubricating Oil to Minimize the Pitting Failure of Gear Teeth

Abstract:

Literature reported extensive work on the failure of Industrial power transmission systems, during their routine torque transmission, rotary motion etc. During transmission through gear drive the noise, temperature, stresses, vibration etc are important factors to be considered. When one or more of above exceed certain design limits, the drive and its accessories must be examined for the cause and a preventive maintenance is to be followed. The latest research work carried out, in above area is reviewed. The cause of failure and failure analysis is examined. An attempt is made in this paper, to systematically analyze the modes of failures, the reasons for the same, issues and challenges involved, there in, and measures to be taken for addressing them. This analysis is likely to help the researchers to proceed further in analyzing the failure and to suggest means to prevent failure of gear power transmission systems. The major contribution of present work is, to present the common modes of failure of gear teeth in power transmission systems, and measures to be taken to address the same. In general various additives in the lubricating oil help in controlling initiation of pitting. The present work involves controlling one of the additives namely sulphur in the lubricating oil to control pitting. The present work forms an excellent basis for identifying various other parameters affecting the pitting failure of gear teeth in a gear box.

• Periodical: Applied Mechanics and Materials (Volumes 813-814)
• Pages: 959-963
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.813-814.959
• Online since: November 2015
• Authors: Kalathur Kumar*, S. Arul
• Keywords: Challenges, Failure, Pitting, Sulphur, Transmission

References

[1] Rexnord, failure analysis gears-shafts-bearings-seals, 108-010, (2008).

[2] Dr. V. Kirov, BucyrusComparison of the AGMA and FEA Calculations of Gears and Gearbox Components Applied in the Environment of Small Gear Company, American Gear Association , (2012).

[3] Carl Byington, Ryan Brewer, Sanket amin, Gear box corrosion prediction via oil condition sensing and model fusion, handbook of corrosion engineering, Mc graw hill, wahington, D.C., (2011).

[4] E D Price1, A W Lees1, and M I Friswell, Detection of severe sliding and pitting fatigue wear regimes through the use of broadband acoustic emission, Proc. IMechE Vol. 219 Part J: J. Engineering Tribology, (2011).

DOI: 10.1243/135065005x9817

[5] Timothy Krantz and Brian Tufts, Pitting and Bending Fatigue Evaluations of a New Case-Carburized Gear Steel, GEARTECHNOLOGY, (2008).

DOI: 10.1115/detc2007-34090

[6] Sundra raja murthy, Machine design, NCBH Publishers, (2003).

[7] PSG design data book, NCBH Publishers, (2010).

[8] FE analysis for failure of tooth with reference to pitting failure, AGMA Tech, Paper, (2010).

[9] Rexnord, Failure analysis of Gears, ASME, (2011).

[10] John, External corrosion of oil and natural gas pipe lines, ASME, (2006).

[11] Malik, Corrosion studies on SS 316 L on low PH high chloride product water medium", ASME hand book, (2007).

[12] Carl, Gear box corrosion prediction via oil condition sensing and model fusion", ASME hand book, (2010).

[13] Price, Detection of severe sliding and pitting failure areas through use of acoustic emission", DOI 10. 1243, (2005).

[14] Tufts, Pitting and bending fatigue evaluation of a new case – carburized gear steel, www. geartechnology. com, (2014).

[15] Predki, Micro pitting of big gear boxes, influence of flank modification and surface roughness, www. geartechnology. com, (2014).
