Assessment of Series Compensator for Ferroresonance Damping in Power System

Abstract:

Nowadays power quality is a critical issue in power system. Moreover the connection of three-phase transformers through underground cables is growing fast in residential, commercial, industrial and rural applications. Due to this increasing situation, the possibilities of having a series connected capacitance and a non-linear inductance, and hence ferroresonance, become more probable. Ferroresonance can also occur in power transformers or reactors by capacitive coupling from neighbouring phases or lines. It is necessary to have a general idea about what would be the best preventive decisions to take in order to avoid unexpected surprises. It is necessary to have an accurate ferroresonance model so that a device that can smoothen the sharp effects of ferroresonance can be found. In this paper, the FACTS device, namely the static synchronous series compensator (SSSC) had been used to mitigate ferroresonance. Results show that using SSSC dramatically decreases and mitigates the ferroresonance shock as well as the instabilities of the network.

• Periodical: Applied Mechanics and Materials (Volume 818)
• Pages: 101-105
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.818.101
• Online since: January 2016
• Authors: Amir Hesam Khavari, Zulkurnain Abdul-Malek*, Chin Leong Wooi
• Keywords: FACTS Device, Ferroresonance Damping, Harmonic Flux Density, Magnetic Flux Density

References

[1] Abdul-Malek Z., MehranZamir K., Salimi B., Mirazimi S. J., Investigation on the Probability of Ferroresonance Phenomenon Occurrence in Distribution Voltage Transformers Using ATP Simulation, Advances in Intelligent Systems and Computing 182 AISC, pp.149-155.

DOI: 10.1007/978-3-642-32063-7_17

[2] Abdul-Malek Z., Mehranzamir K., Salimi B., Nabipour Afrouzi H., Vahabi Mashak S., Investigation of Ferroresonance Mitigation Techniques in Voltage Transformer Using ATP-EMTP Simulation, Jurnal Teknologi, 64: 4 (2013), 73-77.

DOI: 10.11113/jt.v64.2107

[3] Abdul-Malek Z., Mirazimi S.J., MehranZamir K., Salimi B., Effect of Shunt Capacitance on Ferroresonance Model for Distribution Voltage Transformer, Proceedings of 2012 IEEE Symposium on Industrial Electronics and Applications (ISIEA2012), pp.124-129, Bandung, Sep (2012).

DOI: 10.1109/isiea.2012.6496613

[4] K. R Padiyar, FACTS devise controller in power transmission and distribution, new age international publisher, banglore, (2007).

[5] Rezaei-Zare, A.I., R.; Sanaye-Pasand, M.; Mohseni, H.; Farhangi, S., An Accurate Hysteresis Model for Ferroresonance Analysis of a Transformer. Power Delivery, IEEE Transactions, July 2008. 23(3): p.1448 – 1456.

DOI: 10.1109/tpwrd.2007.916225

[6] Arab, H.F., F., Implementation of Preisach-type model for studying of B-H curve influence on the behavior of flux-coupling type SFCL. October. 2009 pp.1-6.

DOI: 10.1109/epec.2009.5420903

[7] Li, H.L.Q.L.X. -b.X.T.L.L., A Modified Method for Jiles-Atherton Hysteresis Model and Its Application in Numerical Simulation of Devices Involving Magnetic Materials. Electromagnetic Field Computation (CEFC), 2010 14th Biennial IEEE Conference, May 2010 pp.1-1.

DOI: 10.1109/cefc.2010.5481469

[8] L. Gyugyi, Dynamic compensation of AC transmission lines by solid-state synchronous voltage sources, IEEE Trans. on Power Delivery, v. 9, n. 2, 1994, pp.904-911.

DOI: 10.1109/61.296273

[9] K.K. Sen, SSSC-static synchronous series compensator: theory, modelling and applications, IEEE Trans. on Power Delivery, v. 13, n. 1, 1998, pp.241-246.

DOI: 10.1109/61.660884

[10] C. Hatziadoniu and A.T. Funk, Development of a control scheme for aseries connected solid state synchronous voltage source, IEEE Trans. on Power Delivery, v. 11, n. 2, April 1996, pp.1138-1144.

DOI: 10.1109/61.489378
